Notifier NFXI-BEAM-TE NFXI-BEAM-E analog barrier with integrated…

NFXI-BEAM-E analog barrier with integrated sensitivity test function. Maximum capacity 70m

• Addressable beam smoke detector, composed of a single > optical unit (TRX) and two reflectors to be placed on the opposite side.
• Protection range between 0 and 75 meters or up to 100 with the > special reflector.
• Sensitivity adjustable in six levels with two variables according to the > environment.
• Automatic dusty gain compensation for signal loss.
• Easy alignment thanks to adjustment buttons, staff alignment > and digital readout of signal strength.
• Alarm and fault contact.
• Thanks to the special built-in interface it can communicate with the control > panel and addressing is done via rotary > switches (01 to 99).
• CPD certificate in accordance with EN 54 part 12.
• Operating voltage 15-32VDC.
• Standby consumption 2mA, and 8.5mA in case of alarm.
• Operating temperature -30°C to +55°C.
• Relative humidity up to 93% (non-condensing).
• IP 54 degree of protection.
• With integrated sensitivity test function.
• Maximum capacity 70m. >
