Data sheet

Weight

1900 g

Power

12VDC / 5W, PoE IEEE802.3at

Temp. operation

-40º C ~ +60º C

Degree of protection

Weatherproof IP66

Dimensions

47.1 (H) x 37.9 (W) x 14.2 (D) mm
388 mm (D) x 110 (Ø) mm

Alarm

2/2 In/Out

Compatibility

AJ-BUTTON-B and AJ-DOUBLEBUTTON-B

Audio

1 input / 1 output line level 600 ohm

Lens

15 mm

Viewing angle

25º x 19º

Internal memory

Micro SD card up to 128GB

Remote access

WEB interface, CMS (SunView), Smartphone and NVR

Main Stream rate

D1 (25fps)

Extra Stream rate

VAT NUMBER (25fps)

Compression

H.265 / H.264 / MJPEG

Network interface

Ethernet 10/100 BaseT

Interoperability

ONVIF

Intelligent functions

Fire detection and alarm, crossover, intrusion

Thermal sensor

400x300 VOx

VCA ranges

Fire detection: 441 m Person detection: 441 m Vehicle detection: 1353 m Fire recognition: 147 m Person recognition: 110 m Vehicle recognition: 338 m
Fire detection: 441 m Person detection: 441 m Vehicle detection: 1353 m Fire recognition: 147 m Person recognition: 110 m Vehicle recognition: 338 m

Thermal sensitivity

≤40mK

Spectral range

8~14um

VCA

Up to 8 VCA rules (cross line, intrusion, area entry and exit)

Temperature rules

Even 19 rules (9 points, 9 areas and 1 line)

Range of Detectable Temperatures

-40 ℃ to 150 ℃ ( from -4 ℉ to ℉ 302 )
