T.0X Optical Amplifier 1i/1o: 1550nm SC/APC 20dBm Televes
The module amplifies the 1550 nm optical signal producing an optical output power of 20 dBm. Based on EDFA (erbium doped fibre) technology, it provides a high gain and a low noise factor.
€79.82
€122.80
Save 35%
Tax included
Reference
televes-234220
Brand
Televes
![Safire SF-IPB025WHA-4PW - 4 MP IP Camera, 1/2.7\" Progressive Scan CMOS, H.265 /…](https://dm.orbitadigital.es/294874-medium_default/t0x-optical-amplifier-1i1o-1550nm-scapc-20dbm-televes.jpg "Safire SF-IPB025WHA-4PW - 4 MP IP Camera, 1/2.7\\" Progressive Scan CMOS, H.265 /…")
T.0X Optical Amplifier 1i/1o: 1550nm SC/APC 20dBm Televes
€79.82
€122.80
Save 35%
1-output EDFA optical amplifier
1550 nm, Po 20 dBm
The module amplifies the 1550 nm optical signal producing an optical output power of 20 dBm. Based on EDFA (erbium doped fibre) technology, it provides a high gain and a low noise factor.
Highlights
- -3 dBm to +10 dBm input range
- Status LED indicators
Features
- Optical amplification for the RF service over fibre (RF Overlay)
- Suitable for long distances
- SC/APC connectors
Specifications
| Optical bandwidth | nm | 1550 ±15 |
| Input optical power | dBm | -3 ... +10 |
| Output optical power | dBm | 20 ±0.8 |
| Noise figure | dB | < 5 |
| Return losses | dB | > 50 |
| C/N | dB | > 53 |
| CSO - CENELEC 42 CH | dBc | > 61 |
| CTB - CENELEC 42 CH | dBc | > 61 |
| Powering | V= | 24 ±5% |
| Max. current consumpt | mA | 300 @24V= |
| Optical connectors | Type | SC/APC |
| Operating temperature |
ºC ºF |
-5 ... +45 +23 ... +113 |
| Protection index | IP | 20 |
Application example
Data sheet
- Weight
- 450 g
- Power
- DC 12 V / 0.6 A
- Temp. operation
- -30º C ~ +60º C
- Degree of protection
- Weatherproof IP66
- Dimensions
- 175.6 (D) x 73 (H) x 89 (W) mm
- Material
- Front cover: metal, back cover: plastic
- Audio
- 1 Built-in microphone, 1 Speaker
- Image sensor
- 1/2.7\" Progressive Scan CMOS
- Minimum illumination
- 0.009 Lux / F1.6
- Lens
- 2.8 mm (H: 97º, V: 52º, D: 114º)
- Maximum resolution
- 4 Megapixel (2560x1440)
- Infrared lighting
- 0 Lux / Matrix LED IR (30 m)
- Image improvements
- BLC, HLC, 35 DNR
- Day / Night
- Auto / Programmable / Colour / BW (Black and White)
- Base dimensions
- 3 screws (Ø55 ) mm
- Alarms
- No
- Internal memory
- SD card (up to 256 GB)
- Remote access
- Web browser, Safire Control Center Smartphone App and PC Software
- Main Stream rate
- 4Mpx / 1080p / 720p (1 ~25 FPS)
- Extra Stream rate
- 640×360 / 640×360 (1 ~ 25 FPS)
- Compression
- H.265 / H.264
- Network interface
- Ethernet 10/100 BaseT \ Wi-Fi IEEE802.11 b/g/n
- Interoperability
- ONVIF, PSIA, CGI, ISAPI
- Video Bit Rate
- 32 Kbps~8Mbps
- Advanced features
- Motion detection, Alarm with deterrent flash, Audible alarm and Exception (Network disconnection, IP conflict, Illegal access, Memory full, Memory failure)
The module amplifies the 1550 nm optical signal producing an optical output power of 20 dBm. Based on EDFA (erbium doped fibre) technology, it provides a high gain and a low noise factor.
