Network Cable RJ45 S/FTP Cat 6A Cu LSFH 5m Gray Televes

Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6A data cable, S/FTP type (foiled pairs and foiled cable), with a flexible copper inner conductor 26 AWG and outer sheath made of grey LSFH (Low Smoke Free of Halogen). 5m

€102.95
Tax included
Reference televes-209105
Brand Televes
Quantity
Available in 24/48h

Free shipping
Uniview Pro UV-IPC6322SR-X33UP-D - 2 MP Motorised IP Camera, Prime range, 1/2.8”…

Network Cable RJ45 S/FTP Cat 6A Cu LSFH 5m Gray Televes

€102.95

Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6A data cable, S/FTP type (foiled pairs and foiled cable), with a flexible copper inner conductor 26 AWG and outer sheath made of grey LSFH (Low Smoke Free of Halogen). 5m

Highlights

  • Category-6A data cable
  • S/FTP Foiled FTP Cable (foiled pairs)
  • Flexible copper inner conductor (26 AWG)
  • Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices

Main features

  • PE (Polyethylene) copper conductor insulation, 1.1 mm diameter
  • Aluminium+polyester shielding foil
  • Aluminium outer shielding braid
  • Grey LSFH (Low Smoke Free Of Halogen) outer sheath, 0.59 mm thick and 6.2 mm diameter
  • 79% nominal speed
  • RJ45 connectors with gold plated connector ends with shell nickel plated

Discover

Data cable category Cat 6A (augmented) has its origins on Cat 6 and it is backwards compatible, with the standards of the inferior categories (Cat 6/5e and Cat 3). Category 6A evolves over category 6, allowing to achieve transmission frequencies of up to 500 MHz (in each pair) and 10 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T, 1000BASE-T and 10GBASE-T compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Transfer rate up to 10Gbps
  • Frequency range of up to 500 MHz
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 93,8 ohms/Km

The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.

Specifications

Type
S/FTP
Class
Cat 6A
Conductor Material Flexible copper
Ø (mm) 0.16 ± 0.008
Conductor type AWG 26
Conductor isolation Material Polyethylene
Ø (mm) 1.1 ± 0.03
Shielding foil Material Aluminium + Polyester
Outer shielding braid Material Aluminium
Outer sheath Material Low Smoke Free of Halogen (LSFH)
Ø (mm) 6.2 ± 0.2
Thickness (mm) 0.59 ± 0.05
Color Grey
Nominal impedance Ω 100 ± 5
Max. conductor resistence Ω/Km < 100
Nominal velocity % 79
Working voltage V 300

FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
1 4.0 65.0 62.0 63.3 60.3 19.0
4 4.2 63.0 60.5 51.2 48.2 19.0
8 5.8 58.2 55.6 45.2 42.2 19.0
10 6.5 56.6 54.0 43.3 40.3 19.0
16 8.2 53.2 50.6 39.2 36.2 18.0
20 9.2 51.6 49.0 37.2 34.2 17.5
25 10.4 50.0 47.3 35.3 32.3 17.0
31,25 11.5 48.4 45.7 33.4 30.4 16.5
62,5 16.4 43.4 40.6 27.3 24.3 14.0
100 20.9 39.9 37.1 23.3 20.3 12.0
200 30.1 34.8 31.9 17.2 14.2 9.0
250 33.9 33.1 30.2 15.3 12.3 8.0
350 40.6 30.6 27.6 12,4 9.4 6.6
450 46.5 28.7 25.7 10.2 7.2 6.0
500 49.3 27.9 24.8 9.3 6.3 6.0
2021-11-22

Data sheet

Power
DC 12 V / 22W, PoE+ IEEE802.3at
Resolution
2 Megapixel (1920x1080)
Temp. operation
-40º C ~ +65º C
Degree of protection
Waterproof IP66 / Surge protection
Video output
RJ45 and BNC
Audio
1 Input / 1 Relay
Image sensor
1/2.8\" Progressive Scan CMOS
Minimum illumination
0.001 Lux (Colour)
Lens
Varifocal 4.5~148.5mm (Optic Zoom 33X)
Infrared lighting
IR LEDs (150 m)
Image improvements
BLC, HLC, EIS, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI, ANR
Day / Night
Mechanical ICR filter
Pan/Tilt Range
Horizontal: 0°~360°, Vertical: -15°~90° auto flip
Preset positions
1024 preset, preset patrol, route patrol, recorded patrol
Alarms
2 In / 1 Out
Internal memory
MicroSD card, Max 256 GB
Remote access
EZStation Web Browser, Smartphone App and PC Software
Compression
Ultra265/H.265/H.264
Ultra 265/H.265/H.264
Network interface
Ethernet 10 / 100 BaseT
Interoperability
ONVIF, PSIA, CGI
Digital zoom
16X
Electronic shutter
1/1s~1/100,000s
Speed between Presets
Horizontal: 200° /s, Vertical: 80° /s
PTZ Control
Via network access, RS485
Dimensions (without bracket)
369 mm (H) x 220 (Ø) mm
Weight (without bracket)
3400 g
Speed
Horizontal: 0.1° ~ 300°/sec, Vertical: 0.1° ~80°/s
