Data sheet

Power supply

DC 12V / 5A

Dimensions / Weight

288 (H) x 375 (W) x 53 (D) mm / 2.0 Kg

Communication

RS485 (PTZ) /2 x USB (Ratón y backup) / RJ45 10/100/1000 (Ethernet)

Audio

4 in / 1 out RCA

Video format

HDTVI / HDCVI / AHD / CVBS / IP

Video inputs

16 Channels BNC (HDTVI / HDCVI / AHD / CVBS)

Bidirectional audio

Reusing the audio input/output

Display resolution

3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720

Total bandwidth

128 Mbps

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Alarms

16 input / 3 relay

Recording method

Manual, programmed, motion detection, alarm, stop

Internal memory

2 SATA HDD up to 10TB (not included)

Remote access

Web browser, mobile phone application or PSS software

Video outputs

1 HDMI 4K, 1 VGA

Video / audio compression

H.265+/H.265/H.264+/H.264 / G.711u

Main Stream coding

4K (7FPS), 6MP (10FPS), 5MP (1~12fps) 4M-N/1080p (1~25/30FPS)

Hybrid configuration

Up to 32 IP Channels (8Mpx), replacing all the BNC channels

Recording resolution

4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF

Extra Stream coding

960H(1fps–15fps), D1/CIF(1fps–25/30fps)

Backup

USB / Red

Video analysis

IVS: Tripwire | Area intrusion | Abandoned object | Face detection

Intelligent functions

Function P2P | POS function | Alarm / audio / update by Coaxial (All-over-Coax)

Detección de movimiento inteligente

Hasta 16 canales capaces de clasificar objetivos entre humanos y vehículos
