Network Cable RJ45 U/UTP Cat 6 Cu PVC 3m White Televes

Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 3m

€74.03 €113.90 Save 35%
Tax included
Reference televes-209004
Brand Televes
Quantity
Available in 24/48h

Free shipping
X-Sense XS01 - X-Sense® Mini Stand-alone Smoke Detector, Battery…

Network Cable RJ45 U/UTP Cat 6 Cu PVC 3m White Televes

€74.03 €113.90 Save 35%

Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 3m

Highlights

  • Category-6 data cable
  • U/UTP Unfoiled UTP Cable
  • Flexible copper inner conductor (24AWG)
  • Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices

Main features

  • PE (Polyethylene) copper conductor insulation, 0.96 mm diameter
  • White PVC (polyvinyl chloride) outer sheath, 0.62 mm thick and 5.7 mm diameter
  • 72% nominal speed
  • RJ45 connectors with gold plated connector ends

Discover

Data cable category Cat 6 complies with the standard for Gigabit Ethernet and it is backwards compatible, with the standards of the inferior categories (Cat 5/5e and Cat 3). Category 6 evolves over category 5E, allowing to achieve transmission frequencies of up to 250 MHz (in each pair) and 1 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T and 1000BASE-T (Gigabit Ethernet) compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Crucifix type padding
  • Transfer rate up to 1Gbps
  • Frequency range of up to 250 MHz
  • Includes rip cord to make it easier to strip the cable
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 117 ohms/Km

The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.

Specifications

Type
U/UTP
Class
Cat 6
Conductor Material Flexible copper
Ø (mm) 0.18 ± 0.008
Conductor type AWG 24
Conductor isolation Material Polyethylene
Ø (mm) 0.96 ± 0.05
Filler Crucifix Yes
Outer sheath Material Polyvinyl chloride (PVC)
Ø (mm) 5.7 ± 0.2
Thickness (mm) 0.62 ± 0.05
Color White
Nominal impedance Ω 100 ± 15
Max. conductor resistence Ω/Km < 117
Nominal velocity % 72
Working voltage V 300

FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
1 4.0 65.0 62.0 63.3 60.3 19.0
4 4.2 63.0 60.5 51.2 48.2 19.0
8 5.9 58.2 55.6 45.2 42.2 19.0
10 6.6 56.6 54.0 43.3 40.3 19.0
16 8.3 53.2 50.6 39.2 36.2 18.0
20 9.3 51.6 49.0 37.2 34.2 17.5
25 10.5 50.0 47.3 35.3 32.3 17.0
31,25 11.7 48.4 45.7 33.4 30.4 16.5
62,5 16.9 43.4 40.6 27.3 24.3 14.0
100 21.7 39.9 37.1 23.3 20.3 12.0
200 31.7 34.8 31.9 17.2 14.2 9.0
250 35.9 33.1 30.2 15.3 12.3 8.0
