Network Cable RJ45 U/UTP Cat 6 Cu PVC 5m White Televes
Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 5m
€81.44
€125.30
Save 35%
Tax included
Reference
televes-209005
Brand
Televes
Network Cable RJ45 U/UTP Cat 6 Cu PVC 5m White Televes
€81.44
€125.30
Save 35%
Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 5m
Highlights
- Category-6 data cable
- U/UTP Unfoiled UTP Cable
- Flexible copper inner conductor (24AWG)
- Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices
Main features
- PE (Polyethylene) copper conductor insulation, 0.96 mm diameter
- White PVC (polyvinyl chloride) outer sheath, 0.62 mm thick and 5.7 mm diameter
- 72% nominal speed
- RJ45 connectors with gold plated connector ends
Discover
Data cable category Cat 6 complies with the standard for Gigabit Ethernet and it is backwards compatible, with the standards of the inferior categories (Cat 5/5e and Cat 3). Category 6 evolves over category 5E, allowing to achieve transmission frequencies of up to 250 MHz (in each pair) and 1 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T and 1000BASE-T (Gigabit Ethernet) compliant systems.
They are characterized for:
- Comply with TIA/EIA-568B.2-1
- Crucifix type padding
- Transfer rate up to 1Gbps
- Frequency range of up to 250 MHz
- Includes rip cord to make it easier to strip the cable
- Nominal impedance of 100 ohms
- Maximum resistance per conductor below 117 ohms/Km
The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.
Specifications
| Type | ||
| U/UTP | ||
| Class | ||
| Cat 6 | ||
| Conductor | Material | Flexible copper |
| Ø (mm) | 0.18 ± 0.008 | |
| Conductor type | AWG | 24 |
| Conductor isolation | Material | Polyethylene |
| Ø (mm) | 0.96 ± 0.05 | |
| Filler | Crucifix | Yes |
| Outer sheath | Material | Polyvinyl chloride (PVC) |
| Ø (mm) | 5.7 ± 0.2 | |
| Thickness (mm) | 0.62 ± 0.05 | |
| Color | White | |
| Nominal impedance | Ω | 100 ± 15 |
| Max. conductor resistence | Ω/Km | < 117 |
| Nominal velocity | % | 72 |
| Working voltage | V | 300 |
| FREQUENCY | ATTENUATION | NEXT | PS-NEXT | ELFEXT | PS-ELFEXT | RETURN LOSS |
| (MHz) | (dB/100m) | |||||
| 1 | 4.0 | 65.0 | 62.0 | 63.3 | 60.3 | 19.0 |
| 4 | 4.2 | 63.0 | 60.5 | 51.2 | 48.2 | 19.0 |
| 8 | 5.9 | 58.2 | 55.6 | 45.2 | 42.2 | 19.0 |
| 10 | 6.6 | 56.6 | 54.0 | 43.3 | 40.3 | 19.0 |
| 16 | 8.3 | 53.2 | 50.6 | 39.2 | 36.2 | 18.0 |
| 20 | 9.3 | 51.6 | 49.0 | 37.2 | 34.2 | 17.5 |
| 25 | 10.5 | 50.0 | 47.3 | 35.3 | 32.3 | 17.0 |
| 31,25 | 11.7 | 48.4 | 45.7 | 33.4 | 30.4 | 16.5 |
| 62,5 | 16.9 | 43.4 | 40.6 | 27.3 | 24.3 | 14.0 |
| 100 | 21.7 | 39.9 | 37.1 | 23.3 | 20.3 | 12.0 |
| 200 | 31.7 | 34.8 | 31.9 | 17.2 | 14.2 | 9.0 |
| 250 | 35.9 | 33.1 | 30.2 | 15.3 | 12.3 | 8.0 |
