SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 33SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 21727 AND id_lang = 1 10-unit box. Network Cable RJ45 U/UTP Cat 6 Cu PVC 0.5m White Televes
  • -35%
Xtralis XTL-60041620 - XTRALIS-ADPRO iFT 16IP, 6TB HDD, 20I/8O, Alarms…
search
  • Xtralis XTL-60041620 - XTRALIS-ADPRO iFT 16IP, 6TB HDD, 20I/8O, Alarms…

10-unit box. Network Cable RJ45 U/UTP Cat 6 Cu PVC 0.5m White Televes

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 0.5m

€57.64 €88.68 Save 35%
Tax included
Reference televes-209011
Brand Televes
Quantity
Out-of-Stock

Free shipping

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 0.5m

Highlights

  • Category-6 data cable
  • U/UTP Unfoiled UTP Cable
  • Flexible copper inner conductor (24AWG)
  • Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices

Main features

  • PE (Polyethylene) copper conductor insulation, 0.96 mm diameter
  • White PVC (polyvinyl chloride) outer sheath, 0.62 mm thick and 5.7 mm diameter
  • 72% nominal speed
  • RJ45 connectors with gold plated connector ends

Discover

Data cable category Cat 6 complies with the standard for Gigabit Ethernet and it is backwards compatible, with the standards of the inferior categories (Cat 5/5e and Cat 3). Category 6 evolves over category 5E, allowing to achieve transmission frequencies of up to 250 MHz (in each pair) and 1 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T and 1000BASE-T (Gigabit Ethernet) compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Crucifix type padding
  • Transfer rate up to 1Gbps
  • Frequency range of up to 250 MHz
  • Includes rip cord to make it easier to strip the cable
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 117 ohms/Km

The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.

Specifications

Type
U/UTP
Class
Cat 6
Conductor Material Flexible copper
Ø (mm) 0.18 ± 0.008
Conductor type AWG 24
Conductor isolation Material Polyethylene
Ø (mm) 0.96 ± 0.05
Filler Crucifix Yes
Outer sheath Material Polyvinyl chloride (PVC)
Ø (mm) 5.7 ± 0.2
Thickness (mm) 0.62 ± 0.05
Color White
Nominal impedance Ω 100 ± 15
Max. conductor resistence Ω/Km < 117
Nominal velocity % 72
Working voltage V 300

FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
1 4.0 65.0 62.0 63.3 60.3 19.0
4 4.2 63.0 60.5 51.2 48.2 19.0
8 5.9 58.2 55.6 45.2 42.2 19.0
10 6.6 56.6 54.0 43.3 40.3 19.0
16 8.3 53.2 50.6 39.2 36.2 18.0
20 9.3 51.6 49.0 37.2 34.2 17.5
25 10.5 50.0 47.3 35.3 32.3 17.0
31,25 11.7 48.4 45.7 33.4 30.4 16.5
62,5 16.9 43.4 40.6 27.3 24.3 14.0
100 21.7 39.9 37.1 23.3 20.3 12.0
200 31.7 34.8 31.9 17.2 14.2 9.0
250 35.9 33.1 30.2 15.3 12.3 8.0
2021-10-18

Data sheet

Operating temperature
5–40 °C
Power supply
100–240 VCA, 50/60 Hz
Video output
XGA – Multiple matrix views
Audio output
Standard: 1 line output. Optional: up to 1 per camera via audio switcher. Audio output on IP cameras (depending on the camera) with ONVIF Profile S/T controller
Humidity
from 20-93 % RH non-condensing
Operating system
ADPRO® XO™ Security operating system, based on Linux
Management
Web client interface (XO client), ADPRO VideoCentral Platinum, third-party software (SDK available) and iTrace App for iOS/Android
Relay outputs
8 outputs on the box (SPDT) + 8 outputs (SPDT) with USB XO I/O interface module + 128 outputs (SPDT) with Net I/O module with PoE
Video Resolution
Up to HD/MP resolution (Depending on the camera)
Video analysis
Basic motion detection (VMD), camera sabotage detection. Up to 16 analysis channels IntrusionTrace™ and LoiterTrace™ (datasheets available separately)
Ethernet
2 x 100/1000BASE-T, autodetection, full duplex, RJ45
Video compression
H.264/H.265 (H.265 supported with ONVIF profile S/T, Hikvision and generic drivers)
Video input
1–32 IP cameras (For optimal performance, disable monitor output when using more than 16 IP cameras)
Audio input
Supports built-in audio input (Depending on the camera)
Images/second
Full HD @25/30 ips – Megapixels: ips is depending on the camera
Bandwidth Capacity
32 x 5 Mbps
Bandwidth Management
Configurable bitrate constant or variable / Configurable bandwidth limiter
Command inputs
20 inputs in the box (monitored) + 20 inputs (monitored) with USB XO I/O interface module + 128 with Net I/O module with PoE
Web server
XO Client - Integrated Web Client Application (ActiveX)
Recording Type
Schedule / Detection / Event
IP Camera Integration
Brand-specific, generic or with driver ONVIF S/T profile (Depends on the camera)
Disk Capacity
Max. 4 x SATA 10 TB HDD. Compatibility with RAID 1. 2 Identical HDD)
Warranty
2 years
Dimensions (W x H x L)
441 x 88 x 305 mm
Mobile Apps
iTrace, iPIR
