10-unit box. Network Cable RJ45 U/UTP Cat 6 Cu PVC 2m White Televes

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 2m

€37.59 €57.83 Save 35%
Tax included
Reference televes-209013
Brand Televes
Quantity
Available in 24/48h

Free shipping
Xtralis XTL-670021360 - XTRALIS ADPRO eFT 8IP 2TB HDD 4I/2O, Alarms 4I/2O,…

10-unit box. Network Cable RJ45 U/UTP Cat 6 Cu PVC 2m White Televes

€37.59 €57.83 Save 35%

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 2m

Highlights

  • Category-6 data cable
  • U/UTP Unfoiled UTP Cable
  • Flexible copper inner conductor (24AWG)
  • Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices

Main features

  • PE (Polyethylene) copper conductor insulation, 0.96 mm diameter
  • White PVC (polyvinyl chloride) outer sheath, 0.62 mm thick and 5.7 mm diameter
  • 72% nominal speed
  • RJ45 connectors with gold plated connector ends

Discover

Data cable category Cat 6 complies with the standard for Gigabit Ethernet and it is backwards compatible, with the standards of the inferior categories (Cat 5/5e and Cat 3). Category 6 evolves over category 5E, allowing to achieve transmission frequencies of up to 250 MHz (in each pair) and 1 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T and 1000BASE-T (Gigabit Ethernet) compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Crucifix type padding
  • Transfer rate up to 1Gbps
  • Frequency range of up to 250 MHz
  • Includes rip cord to make it easier to strip the cable
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 117 ohms/Km

The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.

Specifications

Type
U/UTP
Class
Cat 6
Conductor Material Flexible copper
Ø (mm) 0.18 ± 0.008
Conductor type AWG 24
Conductor isolation Material Polyethylene
Ø (mm) 0.96 ± 0.05
Filler Crucifix Yes
Outer sheath Material Polyvinyl chloride (PVC)
Ø (mm) 5.7 ± 0.2
Thickness (mm) 0.62 ± 0.05
Color White
Nominal impedance Ω 100 ± 15
Max. conductor resistence Ω/Km < 117
Nominal velocity % 72
Working voltage V 300

FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
1 4.0 65.0 62.0 63.3 60.3 19.0
4 4.2 63.0 60.5 51.2 48.2 19.0
8 5.9 58.2 55.6 45.2 42.2 19.0
10 6.6 56.6 54.0 43.3 40.3 19.0
16 8.3 53.2 50.6 39.2 36.2 18.0
20 9.3 51.6 49.0 37.2 34.2 17.5
25 10.5 50.0 47.3 35.3 32.3 17.0
31,25 11.7 48.4 45.7 33.4 30.4 16.5
62,5 16.9 43.4 40.6 27.3 24.3 14.0
100 21.7 39.9 37.1 23.3 20.3 12.0
200 31.7 34.8 31.9 17.2 14.2 9.0
250 35.9 33.1 30.2 15.3 12.3 8.0

Data sheet

Operating temperature
from 0 to 40°C
Power supply
12 VCC, 5A, 60W (power supply 230 VAC/12 VCC included)
Video output
HDMI: 2 × HDMI interface, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, (1920 × 1080)/60Hz, (1600 × 1200)/60Hz, (1280 × 1024)/60Hz, (1280 × 720)/60Hz, (1024 × 768)/60Hz VGA: 1 × VGA interface, (1920 × 1080)/60Hz, (1280 × 1024)/60Hz, (1280 ×
Audio output
Analog audio output ( 3,5 mm connector) and digital audio output from IP cameras. Support for zone-specific audio
Humidity
from 10 to 93% non-condensing humidity
Operating system
Operating system ADPRO® XO™ Security, based on Linux
Management
Web client interface (XO client), ADPRO VideoCentral Platinum, third party software (SDK available) and iTrace app for iOS/Android
Relay outputs
2 outputs in the box
Video Resolution
Up to 4K resolution, For optimal performance, when using 4K cameras on XO devices, the number of supported cameras and analysis channels (IntrusionTrace and/or LoiterTrace) are reduced in proportion to the resolution.
Video analysis
Basic: Motion detection, Manipulation Up to 8 xTrace Analytics channels: IntrusionTrace™, LoiterTrace™ (requires optional licenses)
Video compression
H.264/H.265 (H.265 compatible with Hikvision, Honeywell, ONVIF S/T profile and generic controller)
Audio input
Audio input from compatible IP camera
Images/second
Full HD/1080p to 25/30 fps (PAL/NTSC)
Bandwidth Management
Configurable bitrate constant or variable / Bandwidth limiter configurable
Web server
XO Client - Integrated Web Client Application (ActiveX)
Recording Type
Schedule/Detection/Event
IP Camera Integration
Driver específico según la marca, genérico o driver ONVIF Perfil S/T (Depende de la cámara)
Warranty
2 years
Bandwidth (video)
16 x 5 Mbps
Built-in inputs
4 inputs in the box
External inputs
(Via XO USB I/O (monitored) + Network I/O unit with PoE 20 Entradas monitorizadas (con una conexión USB sencilla utilizando USB o E/S de alarma externa) 40 Monitored inputs (with dual USB connection using USB or external alarm I/O) Up to 128 monitore
External relay outputs
(Via XO USB I/O (monitored) + Network I/O unit with PoE 8 Monitored outputs (with a simple USB connection using USB or external alarm I/O) 16 Relay outputs (with dual USB connection using USB or external alarm I/O) Up to 128 Relay outputs via Ethernet
SATA / Max HDD Storage.
2TB / 2 x 10TB
Ethernet network
2 x RJ45: Self-adapting Ethernet interfaces 10M/100M/1000M
PoE Support
No
Dimensions (length x width x height)
445mm × 290mm × 45mm
19\" Compatible bracket
No
