Data Connector RJ45 UTP Cat 6 Male with White Shield Televes (Box 25 units)
RJ45 UTP Cat 6 male + White PVC Protective Sleeve. connector to connect data cables. Multiple-connection guaranteed without losses. Compatible with Cat 6 or below. Mounting requires a crimping plier. Gold-plated pins. Supplied in 25-unit professional plastic box.
€54.47
Tax included
Reference
televes-209961
Brand
Televes
Data Connector RJ45 UTP Cat 6 Male with White Shield Televes (Box 25 units)
€54.47
RJ45 UTP Cat 6 male connector + White PVC Protective Sleeve to connect data cables.
Supplied in 25-unit professional plastic box.
Highlights
- Multiple-connection guaranteed without losses
Main features
- Compatible with Cat 6 or below
- Mounting requires a crimping plier
- Gold-plated pins
Specifications
| IDC N.º | EIA/TIA 568 A | EIA/TIA 568 B | ||
| Pair | Wire colour | Pair | Wire colour | |
| PIN5 | 1 | White/Blue | 1 | White/Blue |
| PIN4 | Blue | Blue | ||
| PIN1 | 3 | White/Green | 2 | White/Orange |
| PIN2 | Green | Orange | ||
| PIN3 | 2 | White/Orange | 3 | White/Green |
| PIN6 | Orange | Green | ||
| PIN7 | 4 | White/Brown | 4 | White/Brown |
| PIN8 | Brown | Brown | ||
