Coil 100 m Multi-fibre cable 16 single-mode fibres Dca Euroclass and UV-resistant LSFH, indoor/outdoor Televes

16-fibre cable with UV-resistant LSFH sheath for indoor and outdoor installation. Divided in 4 micro-modules of 4 fibres each, each with its own LSFH sheath and different colour. This provides a better organization and makes identification easier. Coil 100 m

€22.00 €33.84 Save 35%

Tax included

Reference televes-231414

Brand Televes

$RACK-6U-MESH - Rack cabinet for wall, Up to 6U rack of 19\", Up to 60…$

Coil 100 m Multi-fibre cable 16 single-mode fibres Dca Euroclass and UV-resistant LSFH, indoor/outdoor Televes

€22.00 €33.84 Save 35%

Description
Product Details

Multi-fibre cable 16 single-mode fibres

Dca Euroclass and UV-resistant LSFH, indoor/outdoor

Coil 100 m

Highlights

Dca-s2,d2,a1 Euroclass
Low attenuation
Organized in fibre micro-modules
Blocking jelly, offering great protection against water
Good structure reinforcement using aramid fibers (kevlar), which allows to maintain its traction without the need for a central guiding wire for resistance

Features

9/125, ITU-T G.657A2 fibre type
Coating diameter adapted to the fibre: 250 μm
Ripcord to open the outer sheath
UV-resistant LSFH sheath, orange colour

Specifications

Cable type			Indoor/Outdoor
Fibre type			9/125 (G657A2)
Number of fibres			16
Attenuation	1310nm	dB/Km	≤0,4
Attenuation	1550nm	dB/Km	≤0,3
Micro-modules	Material		LSFH (Low Smoke Free Halogen)
	Filler		Water blocking petrol-jelly
	Diameter	mm	0,85 ±0,05
Outer sheath	Material		UV-resistant LSFH (Low Smoke Free Halogen)
	Color		Orange
	Diameter	mm	7,6 ±0,4
Min. bending radius		mm	76
Short tension		N	1000
Short crush		N/100mm	1000
Operating temperature		ºC	-5 ... 60

Data sheet

Degree of protection: IP20
Material: SPCC steel
Maximum load: 60 kg
Interior dimensions: 465 (w) x 450 (d) mm
Rack type: Wall closet
Storage capacity: Up to 6U rack of 19\"
