Data sheet

Weight

2.5Kg

Dimensions

370 x 410 x 80 mm

Temperature

-5ºC~+45ºC

Primary power supply

Fuente conmutada 187-252V AC 50-60 Hz 65W max.
Switching source 187-252V AC 50-60 Hz 65W max.

Backup power supply

2 baterías 12VDC (hasta 18 Ah). Asegura mínimo 72 horas de duración.
2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.

Number of zones

16 zonas, hasta 30 detectores por zona.
16 zones, up to 30 detectors by area.

Siren outputs

2 siren outputs 24VDC. Independent and monitored open collector outputs

Relay outputs

8 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
8 Salidas de Relé: 1 Salida de Alarma, 1 Salida de fallo y 6 salidas de relé configurables. Todas admiten 30VDC 3A máx.

End of line resistance

Areas fully monitored by end-of-line resistance (4.7K)

Auxiliary Output Voltage

24VDC. Protected by resettable electronic fuse 1.85A
24VDC. Protegido por fusible electrónico rearmable 1.85A

Protection Index

IP30

Material and colour

ABS, colour: White

Recommended cable

Fire cable with a minimum section of 1.0mm (18AWG).

Available languages

Español, inglés, portugués, italiano, francés, y alemán.
Spanish, English, Portuguese, Italian, French, and German.
