10-unit box. Network Cable RJ45 U/UTP Cat 6 Cu PVC 20m White Televes

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 20m

€208.77 €321.18 Save 35%
Tax included
Reference televes-209018
Brand Televes
Quantity
Out-of-Stock

Free shipping

10-unit box. Preconnected data patch cord with RJ45 connector at each end. It is made of a Category-6 data cable, U/UTP type, with a flexible copper inner conductor 24 AWG and outer sheath made of white PVC. 20m

Highlights

  • Category-6 data cable
  • U/UTP Unfoiled UTP Cable
  • Flexible copper inner conductor (24AWG)
  • Compatible with PoE/PoE+ (Power over Ethernet) technology, allowing the cable to power network devices

Main features

  • PE (Polyethylene) copper conductor insulation, 0.96 mm diameter
  • White PVC (polyvinyl chloride) outer sheath, 0.62 mm thick and 5.7 mm diameter
  • 72% nominal speed
  • RJ45 connectors with gold plated connector ends

Discover

Data cable category Cat 6 complies with the standard for Gigabit Ethernet and it is backwards compatible, with the standards of the inferior categories (Cat 5/5e and Cat 3). Category 6 evolves over category 5E, allowing to achieve transmission frequencies of up to 250 MHz (in each pair) and 1 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T and 1000BASE-T (Gigabit Ethernet) compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Crucifix type padding
  • Transfer rate up to 1Gbps
  • Frequency range of up to 250 MHz
  • Includes rip cord to make it easier to strip the cable
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 117 ohms/Km

The RJ45 is a connector commonly used in structured cable networks. With up to 8 connection pins, it is adequate both for data networks (8 pairs), as well as telephone networks (2 pairs). It is usually used in networks compliant with standards TIA/EIA-568-B.

Specifications

Type
U/UTP
Class
Cat 6
Conductor Material Flexible copper
Ø (mm) 0.18 ± 0.008
Conductor type AWG 24
Conductor isolation Material Polyethylene
Ø (mm) 0.96 ± 0.05
Filler Crucifix Yes
Outer sheath Material Polyvinyl chloride (PVC)
Ø (mm) 5.7 ± 0.2
Thickness (mm) 0.62 ± 0.05
Color White
Nominal impedance Ω 100 ± 15
Max. conductor resistence Ω/Km < 117
Nominal velocity % 72
Working voltage V 300

FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
1 4.0 65.0 62.0 63.3 60.3 19.0
4 4.2 63.0 60.5 51.2 48.2 19.0
8 5.9 58.2 55.6 45.2 42.2 19.0
10 6.6 56.6 54.0 43.3 40.3 19.0
16 8.3 53.2 50.6 39.2 36.2 18.0
20 9.3 51.6 49.0 37.2 34.2 17.5
25 10.5 50.0 47.3 35.3 32.3 17.0
31,25 11.7 48.4 45.7 33.4 30.4 16.5
62,5 16.9 43.4 40.6 27.3 24.3 14.0
100 21.7 39.9 37.1 23.3 20.3 12.0
200 31.7 34.8 31.9 17.2 14.2 9.0
250 35.9 33.1 30.2 15.3 12.3 8.0
2021-10-18

Data sheet

Weight
354 g
Dimensions
90 (H) x 120 (W) x 33.5 (D) mm
Consumption
2 x batteries (R6) 1.5V
2 x pilas (R6) 1.5V
Temperature measurement range
-40ºC~1000ºC±(1%+3)
Precisión
Tensión DC: ±(0.5%+2) Tensión AC: ±(0.8%+3) Intensidad DC: ±(0.7%+2) Intensidad AC: ±(1%+3)
Accuracy
DC voltage: ±(0.5%+2) AC voltage: ±(0.8%+3) DC current: ±(0.7%+2) AC current: ±(1%+3)
Rango de medida de resistencia
60MΩ±(0.8%+2)
Rango de medida de capacitancia
99.99mF ±(4%+5)
Rango de medida de frecuencia
10Hz~10MHz±(0.1%+4)
Cuentas display
Hasta 6000
Dimensiones display
58mm x 36mm
Auto Rango / Rango manual / True RMS
Sí dispone
Test de diodos
Alrededor de 3V
Test de continuidad
Si dispone
Rango de medida tensión DC y AC
600V
Rango de medida de intensidad DC y AC
10A
Banda ancha
45Hz~1kHz
LPF/LoZ (ACV) (Medición de voltaje fantasma)
No dispone
Resistance measuring range
60MΩ±(0.8%+2)
Capacitance measuring range
99.99mF ±(4%+5)
Frequency measurement range
10Hz~10MHz±(0.1%+4)
Display accounts
Up to 6000
Display dimensions
58mm x 36mm
Auto Range / Manual Range / True RMS
Yes, it has
Diode test
Around 3V
Continuity test
Yes, it is available
Measuring range DC and AC voltage
600V
DC and AC current measuring range
10A
Broadband
45Hz~1kHz
LPF/LoZ (ACV) (Phantom Voltage Measurement)
No
