RJ45 female connector FTP Cat 6 for data cables Televes (Box 10 units)
RJ45 FTP Cat 6 female connector, reusable and easy to connect since no specific tools are required. Self-crimpable connector (no specific tool required). Reusable: can be removed and reinstalled without deteriorating or losing functionality. Multiple-connection guaranteed without losses. Supplied in 10-unit professional plastic box.
€44.44
€68.37
Save 35%
Tax included
Reference
televes-209903
Brand
Televes
RJ45 FTP Cat 6 female connector, reusable and easy to connect since no specific tools are required.
Supplied in 10-unit professional plastic box.
Highlights
- Self-crimpable connector (no specific tool required)
- Reusable: can be removed and reinstalled without deteriorating or losing functionality
- Multiple-connection guaranteed without losses
Main features
- Compatible with Cat 6A or below
- Connection table (A or B) on the connector
- Gold-plated pins
Specifications
| Electrical | |
| Voltage rating | 150 V c.c RMS |
| Current rating | 1,5 A |
| Contact resistance | 100 mΩ |
| Insulation resistance | 500 MΩ |
| Dielectric streght | 1000 60 Hz / 1 min |
| Optimal for categories | 5FTP, 5e FTP, 6FTP Cat. |
| Mechanical | |
| Operative life | 1500 Times plugging 1 |
| Weight | 21,4 g |
| Measurement | 16,1 x 16 x 38 mm |
Application example
2021-10-18
Data sheet
- Weight
- 150 g
- Power
- DC 12 V / 300 mA max.
- Temp. operation
- -30º C ~ +60º C
- Degree of protection
- IP65
- Dimensions
- 65 (D) x 90 (Ø) mm
- Range
- 1080p ECO
- Video output
- 1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS
HD 1080p (1920x1080) at 25 FPS - Image sensor
- 1/2.7\" Brigates© 2 Megapixel (BG0806)
- Minimum illumination
- 0 Lux / SMD LEDs IR(25 m)
- Basic functions
- OSD menu, Day/Night with IR-CUT (ICR)
- Configurable OSD functions
- DWDR, 2D-NR, AE, AWB, AGC
- Lens
- 3.6 mm (D: 60º)
- DSP associated with the sensor
- V30E
RJ45 FTP Cat 6 female connector, reusable and easy to connect since no specific tools are required. Self-crimpable connector (no specific tool required). Reusable: can be removed and reinstalled without deteriorating or losing functionality. Multiple-connection guaranteed without losses. Supplied in 10-unit professional plastic box.
