Data cable S/FTP CAT-6 Cca LSFH Ø 6.9mm White 500m Televes

Category-6A and Cca Euroclass data cable, U/FTP type (Foiled pairs), with copper conductor and LSFH sheath (Low Smoke Free of Halogen), white colour (RAL 9010). Supplied in a 500m wood reel.

€210.29 €323.53 Save 35%
Tax included
Reference televes-219302
Brand Televes
Quantity
Available in 24/48h

Free shipping
Uniarch UV-IPC-T124-PF40 - Cámara IP 4 Megapixel, Gama Uniarch, 1/2.7\"…

Data cable S/FTP CAT-6 Cca LSFH Ø 6.9mm White 500m Televes

€210.29 €323.53 Save 35%

Category-6A and Cca Euroclass data cable, U/FTP type (Foiled pairs), with copper conductor and LSFH sheath (Low Smoke Free of Halogen), white colour (RAL 9010).

Supplied in a 500m wood reel.

Highlights

  • U/FTP Unfoiled FTP Cable (foiled pairs)
  • Solid copper inner conductor (23AWG)

Features

  • PE (Polyethylene) copper conductor insulation, 1.30mm thick
  • Aluminium foil + polyester between foil and outer cable sheath
  • CuSn ground cable
  • LSFH (Low Smoke Free of Halogen) outer sheath, 0.70mm thick and 6.9mm diameter
  • 79% nominal speed

Data cable category Cat-6A (augmented) has its origins on CAT6 and it is backwards compatible, with the standards of the inferior categories (Cat-6/5e and Cat-3). Category 6A evolves over category 6, allowing to achieve transmission frequencies of up to 500 MHz (in each pair) and 10 Gbps of throughput. It includes characteristics and specifications to avoid crosstalk and noise. This type of data cable can be used in 10BASE-T, 100BASE-T, 1000BASE-T and 10GBASE-T compliant systems.

They are characterized for:

  • Comply with TIA/EIA-568B.2-1
  • Transfer rate up to 10Gbps
  • Frequency range of up to 500MHz
  • Nominal impedance of 100 ohms
  • Maximum resistance per conductor below 93.8 ohms/Km

Specifications

Type   U/FTP
Class   CAT6A
Conductor Material Solid copper
Ø (mm) 0.55 ± 0.01
Conductor type AWG 23
Conductor isolation Material Polyehtylene
Ø (mm) 1.30 ± 0.03
Shielding foil Material Aluminium + Polyester
Outer sheath Material Low Smoke & Free Halogen (LSFH)
Ø (mm) 6.9 ± 0.2
Thickness (mm) 0.70 ± 0.05
Color White
Drain wire Material Tinned copper
Reaction to fire CPR Cca
Nominal impedance Ω 100 ± 15
Max. conductor resistance Ω/Km < 93.8
Nominal velocity % 79
Working voltage V 125
Supply form   Wooden reel
FREQUENCY ATTENUATION NEXT PS-NEXT ELFEXT PS-ELFEXT RETURN LOSS
(MHz) (dB/100m)
0.772 - - - - - -
1 2.1 74.3 72.3 67.8 64.8 20
4 3.8 65.3 63.3 55.8 52.8 23
8 5.3 60.8 58.8 49.7 46.7 24.5
10 5.9 59.3 57.3 47.8 44.8 25
16 7.5 56.3 54.2 43.7 40.7 25
20 8.4 54.8 52.8 41.7 38.8 25
25 9.4 53.3 51.3 39.8 36.8 24.3
31.25 10.5 51.9 49.9 37.9 34.9 23.6
62.5 15.0 47.4 45.4 31.9 28.9 21.5
100 19.1 44.3 42.3 27.8 24.8 20.1
200 27.6 39.8 37.8 21.8 18.8 18
250 31.1 38.3 36.3 19.8 16.8 17.3
300 34.3 37.1 35.1 18.3 15.3 16.8
400 40.1 35.3 33.3 15.8 12.8 15.9
500 45.3 33.8 31.8 13.8 10.8 15.2
2021-10-14

Data sheet

Weight
270 g
Grado de protección
Impermeable IP67
Temp. operation
-30º C ~ 60º C
Dimensions
118.1 (H) x 96.6 (W) mm
Power supply
DC 12 V / 4.5 W, PoE IEEE802.3af
Range
Uniarch
Audio
No
Image sensor
1/2.7” Progressive Scan CMOS
Minimum illumination
0.02 Lux (Colour)
Maximum resolution
4 Megapixel (2560x1440)
Image improvements
DWDR, AGC, 2D/3D-NR, Motion detection, ROI, Privacy Mask, Smart IR
Day / Night
Mechanical ICR filter
Alarms
No
Internal memory
No
Remote access
Navegador Web, Software CMS (EZStation), Smartphone (EZView/EZLive)
Main Stream rate
4 Mpx (1 ~ 20 FPS)
Extra Stream rate
720p (1 ~ 20 FPS)
Compression
Ultra265/H.265/H.264
Network interface
Ethernet 10/100 BaseT
Interoperability
ONVIF
Infrared range
30 m
Lente
4.0 mm
