SC/APC Optical Receiver/Demultiplexer (-5...+2dBm) 1310/1490/1550nm(GPON/TV) 1e/2s Televes
Passive receiver that captures an optical signal on a single fiber (1310/1490/1550nm), and demultiplexes it (WDM). The TV signal (1550nm) is converted to an RF output (54-2400MHz), while the 1310/1490nm wavelengths are destined to data signals (GPON) to distribute them through its optical port.
€235.16
€361.79
Save 35%
Tax included
Reference
televes-237330
Brand
Televes
SC/APC Optical Receiver/Demultiplexer (-5...+2dBm) 1310/1490/1550nm(GPON/TV) 1e/2s Televes
€235.16
€361.79
Save 35%
Passive optical receiver, with WDM
1310/1490/1550nm
Passive receiver that captures an optical signal on a single fiber (1310/1490/1550nm), and demultiplexes it (WDM). The TV signal (1550nm) is converted to an RF output (54-2400MHz), while the 1310/1490nm wavelengths are destined to data signals (GPON) to distribute them through its optical port.
Ideal for applications FTTH/FTTR and as a RF Overlay receiver in GPON networks.
Highlights
- Stable RF signal output level
- DIN rail or wall installation
- Compact and resistant ABS plastic case, white colour (RAL 9003)
Features
- SC/APC optical connectors
- F-type RF connector
Specifications
| RF Output | ||
| Conector de RF | F-Female | |
| Bandwidth | MHz | 54 - 2400 |
| Impedance | Ohm | 75 |
| Planicity | dB | ± 2 |
| Output level | dBμV | 58 (DTT) |
| 49 (SAT) | ||
| Optical input/output | ||
| Number of ports | 1 COM bidirectional 1 GPON bidirectional |
|
| Wavelength | nm | 1310 & 1490 <> GPON 1310 & 1490 <> COM 1550 < COM |
| Maximum optical input power | dBm | +2 |
| Minimum optical input power recommended | dBm | -5 |
| Optical return losses | dB | > 40 |
| Optical connectors | SC/APC | |
| Type of optial device | InGaAs pin photodiode | |
| General | ||
| Operating temperature | ºC | -5 ... +45 |
| Protection index | IP30 | |
Application example
Data sheet
- Power
- DC 12 V / 1.5 A / PoE IEEE802.3af
- Dimensions
- 1U, 48 (H) x 260 (W) x 225 (D) mm / 0.8 Kg (without HDD)
- Communication
- 2x USB 2.0 (Mouse and backup) /1 RJ45 10/100M (Ethernet)
- Inputs for IP cameras
- 16 channels
- Bidirectional audio
- 1 RCA input, 1 RCA output
- Video compression format
- H.265+/H.265/H.264+/H.264/MJPEG
- Total bandwidth
- 80 Mbps
- Simultaneous multifunction
- Pentaplex: Live, Recording, Playback, Backup and Remote Access
- Alarms
- 4 IN / 2 Relay
- Recording method
- Manual, programmed, motion detection
- Internal memory
- 2 SATA HDD 3.5\" of up to 8 TB (not included)
- Remote access
- Web browser (ActiveX), mobile phone application or PSS software
- Video outputs
- 1 HDMI 4K, 1 VGA
- Recording resolution
- 12Mp, 8Mp (on 1 channel), 6Mp, 5Mp, 4Mp, 3Mp, 1080P (on 4 channel), 720P, D1...
- Backup
- USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA internal interface
- Video analysis
- IVS: Line Crossing | Area Intrusion | Face Detection | Face Detection
- Intelligent motion detection
- Up to 2 channels capable of classifying targets amongst humans and vehicles
- Facial recognition
- 1 live analogue face comparison channel
Passive receiver that captures an optical signal on a single fiber (1310/1490/1550nm), and demultiplexes it (WDM). The TV signal (1550nm) is converted to an RF output (54-2400MHz), while the 1310/1490nm wavelengths are destined to data signals (GPON) to distribute them through its optical port.
