High Gain Mast Amplifier (LTE700, 2nd Digital Dividend)

3 inputs: FM-BIII/DAB-UHF

Mast-mounted amplifier to amplify terrestrial television signals from various antennas.

It consists of 3 inputs with amplification in all bands. The amplifier is powered at 24Vdc through the output coaxial cable.

RED compliant.

Stands out for

• Separate amplification of each band
• High gain manual adjustment
• EasyF connection system
• Fully automated manufacturing subjected to rigorous quality controls
• High armor chassis, made of Zamak

Characteristics

• LTE700/5G filter to eliminate telephony interference
• ON/OFF switch to allow DC through to the input, to power a BOSS system
• Simple assembly. Flange for fixing to the mast included
• Durable orange ABS plastic housing for outdoor installation

EasyF connection system: simplicity and savings

The EasyF is an innovative connection concept for the inner conductor of the coaxial (live) cable, which is inserted directly into the device, increasing the reliability of the connection. Furthermore, thanks to the absence of "F" connectors, it is possible to reduce the chassis and secure the connection of two cables with a single screw.

• Real time savings: speeding up the installation is possible, as it is not necessary to make the connectorization of the coaxial cables. In addition, the process of threading the connectors on the device is avoided, which is sometimes complicated when space is not enough.
• Connection reliability: the cable tie that holds the cables prevents the coaxial from loosening
• Cost savings: no additional connector (neither "F" nor "CEI") is required
• Space optimization: inputs and outputs are always located on the same side of the device, avoiding bending of coaxial cables and facilitating work inside cabinets and registers
• Very simple assembly in three steps: you only need to screw and unscrew the covers to connect two cables:

1. Unscrew the cover of the device to access the connection

2. Insert the previously stripped coaxial cables

3. Close the cover and screw to secure the connection

Find out more about the reliability of the EasyF system

With EasyF, the connection of the coaxial cable in the device is carried out by means of an automated system of insertion of the live (internal conductor) by contact, without requiring soldering.

• Like the first day: the life of the device increases by eliminating the possible deterioration of the welds with the passage of time
• Reduced failure rate: generally caused by cold welding
• Optimization of electromagnetic behavior: at high frequencies
• Reinforcement of our commitment to the environment: pollution caused by the welding process is eliminated and electricity consumption in production is reduced

Specifications

Application example
