Tsec CLR-TW-4C-W - High power magnetic contact TSEC, The latest…

High power magnetic contact TSEC - The latest technology in intrusion - Magnasphere technology - Magnetic anti-masking - 4 Thread system - Requires adapter and compatible magnet - Grade 3 approved
€12.43 €19.12 Save 35%
Tax included
Reference CLR-TW-4C-W
Brand Tsec
Quantity
Available in 24/48h

Free shipping
Tsec CLR-TW-4C-W - High power magnetic contact TSEC, The latest…

Tsec CLR-TW-4C-W - High power magnetic contact TSEC, The latest…

€12.43 €19.12 Save 35%

You might also like

  • TSEC
  • Magnetic contact
  • Magnasphere Technology
  • Magnetic anti-masking
  • High resistance to mechanical and electrical shocks
  • 4 Thread system
  • Requires adapter and magnet to work correctly
  • Grade 3 approved

Features

  • High power magnetic contact TSEC
  • The latest technology in intrusion
  • Magnasphere technology
  • Magnetic anti-masking
  • 4 Thread system
  • Requires adapter and compatible magnet
  • Grade 3 approved

Specs

Security grade Grade 3
Environmental class Class 4 / Suitable for outdoor
Technology Magnasphere
Power High power
Maximum detection distance With CRL-MGA: In wood 10 mm
With CRL-AL: On ferrous/non ferrous materials: 5/8 mm
With CRL-BL: In ferrous materials 6 mm
Material Plastic
Cable length 4 wires of 50cm
Magnet Neodymium
Resistance to mechanical shocks Up to 100G
Electrical parameters 30 VDC max, 250 mA, 0.25W
Dimensions 19 x Ø11 mm

Package content

  • Magnetic contact
  • Installation material
  • User instructions

Data sheet

Power
High power
Technology
Magnasphere
Security grade
Grade 3
Dimensions
19 x Ø11 mm
Material
Plastic
Cable length
4 wires of 50cm
Environmental class
Class 4 / Suitable for outdoor
Maximum detection distance
With CRL-MGA: In wood 10 mm With CRL-AL: On ferrous/non ferrous materials: 5/8 mm With CRL-BL: In ferrous materials 6 mm
Magnet
Neodymium
Resistance to mechanical shocks
Up to 100G
Electrical parameters
30 VDC max, 250 mA, 0.25W
