Safire SF-XVR8104S-4KL - Safire 5n1 H.265Pro+ Recorder, Audio over coaxial…

Safire 5n1 H.265Pro+ Recorder - Audio over coaxial cable - 4CH HDTVI/HDCVI/AHD/CVBS/ 4+4 IP - 8Mpx Lite (8FPS) - Full HD HDMI and VGA Output - 1 CH audio / 1 HDD
€110.50 €170.00 Save 35%
Tax included
Reference SF-XVR8104S-4KL
Brand Safire
Quantity
Available in 24/48h

Free shipping
Safire SF-XVR8104S-4KL - Safire 5n1 H.265Pro+ Recorder, Audio over coaxial…

Safire SF-XVR8104S-4KL - Safire 5n1 H.265Pro+ Recorder, Audio over coaxial…

€110.50 €170.00 Save 35%

You might also like

  • Safire
  • DVR 5n1
  • 4 CH video HDTVI/HDCVI/AHD/CVBS / 4+4 IP / 1 CH audio
  • H.265Pro+/H.265Pro/H.264+/H.264
  • Resolution 8Mpx Lite (8FPS) or 1080P/720P (25FPS)
  • Audio over coaxial cable
  • Full HD HDMI and VGA Output
  • Mouse
  • Space for 1 HDD
  • Cloud storage for substream (OneDrive, Dropbox...)

Features

  • Safire 5n1 H.265Pro+ Recorder
  • Audio over coaxial cable
  • 4CH HDTVI/HDCVI/AHD/CVBS/ 4+4 IP
  • 8Mpx Lite (8FPS)
  • Full HD HDMI and VGA Output
  • 1 CH audio / 1 HDD

Specs

Brand SAFIRE
Video format HDTVI / HDCVI / AHD / CVBS / IP
Video inputs 4 Channels BNC, (HDTVI / HDCVI / AHD / CVBS)
Hybrid configuration Default: 4 Channels from BNC and 4 (substitution) + 2 (extra) IP Channels (up to 8Mpx)
Enhanced IP Mode:4 Channels from BNC and 4 (substitution) + 4 (extra) IP Channels (up to 8Mpx)
Enhanced IP mode limits bandwidth to 4Mbps per IP channel
Input bandwidth 32 Mbps
Video outputs 1 HDMI Full HD, 1 VGA
Audio inputs 1 Channel RCA
Audio outputs 1 Channel RCA
Bidirectional audio Reusing the audio input/output
Video / audio compression H.265Pro+ / H.265Pro / H.264+ / H.264 / G.711u
Display resolution 1920x1080, 1280x1024, 1280x720, 1024x768
BNC input resolution 8Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 720p
Main Stream coding 8 Mpx Lite 1 CH (8 FPS) / 3K (12 FPS) / 5Mpx(12 FPS), 1080p / 720p / VGA / WD1 / 4CIF / CIF (25 FPS)
Extra Stream coding WD1 / 4CIF (12FPS) / CIF (25 FPS)
Simultaneous multifunction Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarms No
Video analysis No
Recording method Manual, programmed, motion detection, alarm
Backup USB / Network/ Cloud (Microsoft One Drive, Dropbox)
Internal memory 1 HDD SATA 3.5" of up to 6TB (not included)
Communication RS485 (PTZ) / 2 x USB 2.0 (Mouse and Backup) / RJ45 (Ethernet)
Remote access Web browser, Smartphone App and Safire Control Center CMS Software
Power DC 12 V / 1.5 A (HDD Consumption < 15 W)
Dimensions / Weight 45 (H) x 315 (W) x 242 (D) mm / 1.16 Kg

Package content

  • Safire 5 in 1 DVR
  • Mouse
  • Adapter AC/DC 12 V / 1.5 A
  • CD with manual and software

Data sheet

Power
DC 12 V / 1.5 A (Consumosin HDD ≤ 15 W)
DC 12 V / 1.5 A (HDD Consumption ≤ 15 W)
Power supply
DC 12 V / 1.5 A (Consumosin HDD ≤ 15 W)
Dimensions / Weight
45 (H) x 315 (W) x 242 (D) mm / 1.16 Kg
Communication
RS485 (PTZ) / 2 x USB 2.0 (Mouse and Backup) / RJ45 (Ethernet)
Video format
HDTVI / HDCVI / AHD / CVBS / IP
Video inputs
4 Channels BNC, (HDTVI / HDCVI / AHD / CVBS)
Bidirectional audio
Reusing the audio input/output
Display resolution
1920x1080, 1280x1024, 1280x720, 1024x768
Simultaneous multifunction
Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarms
No
Recording method
Manual, programmed, motion detection, alarm
Internal memory
1 HDD SATA 3.5\" of up to 6TB (not included)
Remote access
Web browser, Smartphone App and Safire Control Center CMS Software
Video outputs
1 HDMI Full HD, 1 VGA
Video / audio compression
H.265Pro+ / H.265Pro / H.264+ / H.264 / G.711u
Main Stream coding
8 MP Lite 1 CH (8 FPS) / 5Mpx(12 FPS), 1080p / 720p / VGA / WD1 / 4CIF / CIF (25 FPS)
8 Mpx Lite 1 CH (8 FPS) / 5 Mpx (12 FPS), 1080p / 720p / VGA / WD1 / 4CIF / CIF (25 FPS)
8 Mpx Lite 1 CH (8 FPS) / 5Mpx (12 FPS), 1080p / 720p / VGA / WD1 / 4CIF / CIF (25 FPS)
Hybrid configuration
Default: 4 Channels from BNC and 4 (substitution) + 2 (extra) IP Channels (up to 8Mpx) Enhanced IP Mode:4 Channels from BNC and 4 (substitution) + 4 (extra) IP Channels (up to 8Mpx) Enhanced IP mode limits bandwidth to 4Mbps per IP channel
Audio inputs
1 Channel RCA
Audio outputs
1 Channel RCA
Extra Stream coding
WD1 / 4CIF (12FPS) / CIF (25 FPS)
Backup
USB / Network/ Cloud (Microsoft One Drive, Dropbox)
USB / Red/ Nube (Microsoft One Drive, Dropbox)
Video analysis
No
Brand
Safire
Input bandwidth
32 Mbps
BNC input resolution
8Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 720p
