Data sheet

Power

DC 12 V / 2 A (Consumosin HDD ≤ 18 W)
DC 12 V / 2 A (HDD Consumption ≤ 18 W)

Operating temperature

-10° ~ +55° C

Power supply

DC 12V / 24W

Dimensions / Weight

45 (H) x 315 (W) x 242 (D) mm / 1.78 Kg
45 (H) x 315 (W) x 242 (D) mm / 2.0 Kg

Communication

2 x USB (Mouse and backup) / Remote control / RJ45 (Ethernet)
RS485 (PTZ) / 2 x USB 2.0 (Mouse and backup) / 1xRJ45 10/100M (Ethernet)

Audio

8ch on Coaxial cable (HDTVI), 1 input / 1 output RCA
16 ch over Coaxial cable (HDTVI), 1 input / 1 RCA output

Video format

HDTVI / HDCVI / AHD / CVBS / IP

Video inputs

16 Channels BNC, (HDTVI / HDCVI / AHD / CVBS)

Bidirectional audio

Reusing the audio input
Using Audio Inputs and RCA Output

Display resolution

1920x1080, 1280x1024, 1280x720, 1024x768 (60 Hz)
HDMI: 1920x1080, 1280x1024, 1280x720, 1024x768 VGA: 1920x1080, 1280x1024, 1280x720, 1024x768

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Alarms

No

Recording method

Manual, programmed, motion detection
Manual, programmed, motion detection, alarm

Internal memory

1 HDD SATA 3.5\" of up to 10TB (not included)
1 SATA HDD 3.5\" of up to 10 TB (not included)

Remote access

Web browser, Smartphone App and Safire Control Center CMS Software

Video outputs

1 HDMI Full HD, 1 VGA, 1 BNC (CVBS) Independent
1 HDMI Full HD, 1 VGA, 1 BNC (CVBS) Independent * HDMI and VGA are simultaneous
1 HDMI Full HD, 1 VGA, 1 BNC (CVBS) Independiente * HDMI and VGA are simultaneous

Video / audio compression

H.265Pro+ / H.265Pro / H.264+ / H.264 / G.711u

Main Stream coding

4 Mpx Lite / 1080P (15 FPS), 720p / VGA / WD1 / 4CIF / CIF (25 FPS)
4Mpx Lite HDTVI (15 FPS) / 1080p Lite / 720p / VGA / WD1 / 4CIF / CIF (25 FPS)

Hybrid configuration

Default: 16 Channels from BNC and 16 (replacement) + 2 (extra) IP Channels (up to 6Mpx) Enhanced IP Mode: 16 Channels from BNC and 16 (replacement) + 8 (extra) IP Channels (up to 6Mpx) Enhanced IP mode limits bandwidth to 4Mbps per IP channel
Default: 16 Channels from BNC and 16 (replacement) + 2 (extra) IP Channels (up to 6Mpx) Enhanced IP Mode: 16Canales desde BNC y 16 (sustitución) + 8 (extra) Canales IP (hasta 6Mpx) Enhanced IP mode limits bandwidth to 4Mbps per IP channel
Up to 18 IP (4 Mpx channels), replacing all BNC channels

Audio inputs

1 ch RCA | 16ch Audio over coaxial cable

Audio outputs

1 ch RCA

Recording resolution

4Mpx Lite HDTVI / 1080p / 1080p Lite / 720p / WD1 / 4CIF / VGA / CIF

Extra Stream coding

WD1 / 4CIF (12FPS) / CIF (25 FPS)

Backup

USB (Memory, HDD, CD-RW, DVR-RW) / Network
USB / Network/ Cloud (Microsoft One Drive, Dropbox)
USB / Red/ Nube (Microsoft One Drive, Dropbox)

Brand

Safire

Audio Bit Rate

64 Kbps

Audio compression

G.711u

Video compression

H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264

Video Bit Rate

32 Kbps at 6 Mbps

Remote connections

128

Artificial intelligence

Behavior detection of people and vehicles to filter false alarms, available in up to 4ch coaxial video Facial recognition up to 1ch

Input bandwidth

96 Mbps

Advanced features

Facial recognition: Up to 1 analog channel for face comparison Truesense: Up to 4 channels (False alarm filter capable of classifying objects between humans and vehicles) Note: TrueSense and Facial Recognition cannot be enabled at the same time.

BNC input resolution

4Mpx / 1080p / 720p

Alarms IN / OUT

No
