Data sheet

Power

DC 12V / 1.5A

Dimensions / Weight

45 (H) x 242 (W) x 315 (D) mm / 1.16 Kg

Communication

RS485 (PTZ) / 2 x USB 2.0 (Mouse and backup) / 1xRJ45 10/100M (Ethernet)

Audio

4ch on Coaxial cable (HDTVI), 1 input / 1 output RCA

Video format

HDTVI / HDCVI / AHD / CVBS / IP

Video inputs

4 Channels BNC (HDTVI / HDCVI / AHD / CVBS)

Bidirectional audio

Using Audio Inputs and RCA Output

Display resolution

1920x1080, 1280x1024, 1280x720

Total bandwidth

64 Kbps

Simultaneous multifunction

Pentaplex: Live, Recording, Playback, Backup and Remote Access

Recording method

Manual, programmed, motion detection, alarm

Internal memory

1 SATA HDD 3.5\" of up to 10 TB (not included)

Remote access

Web browser, Smartphone App and Safire Control Center CMS Software

Video outputs

1 HDMI 1080p, 1 VGA andCVBS

Video / audio compression

H.265+/H.265/H.264+/H.264

Main Stream coding

4Mpx Lite /3 Mpx / 1080p (1~15 FPS), 720p / WD1 / 4CIF / VGA / CIF (1~25 FPS) *3 Mpx is only available for the CH1

Hybrid configuration

Default: 4 Channels from BNC and 4 (replacement) + 1 (extra) IP Channels (up to 6Mpx) Enhanced IP Mode: Channels from BNC and 2 (replacement) + 2 (extra) IP channels (up to 6Mpx)) Enhanced IP mode limits bandwidth to 4Mbps per IP channel
Default: 4 Channels from BNC and 4 (replacement) + 1 (extra) IP Channels (up to 6Mpx) Enhanced IP Mode: Channels from BNC and 4 (replacement) + 2 (extra) IP channels (up to 6Mpx)) Enhanced IP mode limits bandwidth to 4Mbps per IP channel

Extra Stream coding

D1 / 4CIF (1~15 FPS), CIF (25 FPS)

Backup

USB/ Network/ Cloud (Microsoft One Drive, Dropbox)

Brand

Safire

Alarms IN/OUT

4 / 1

Advanced features

Facial recognition: Up to 1 analog channel for face comparison Truesense: Up to 2 channels (False alarm filter capable of classifying objects between humans and vehicles) Note: TrueSense and Facial Recognition cannot be enabled at the same time.

Input resolution

4 Mpx, 3 Mpx, 1080p, 720p, WD1, 4CIF, D1, CIF
