Data sheet

Weight

230 g

Power

DC 12 V / 3 A
DC 12 V / 4W

Grado de protección

IP66 | Sobretensiones 6000V

Resolution

1080P at 25 FPS

Temp. operation

-40º C ~ +60º C

Degree of protection

IP66 | Overvoltages 6000V
Weatherproof IP66

Dimensions

69.66 (D) x 82.6 (Ø) mm

Dimensions (without support)

250 mm (H) x 120 (Ø) mm

Power supply

DC 12 V / 3 A

Material

Metallic

Range

HiWatch Series

Communication

RS485

Video output

1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS
4Mpx (2560x1440) at 25 FPS / 1080p (1920x1080) at 25 FPS
BNC HDTVI format
BNC formato HDTVI

Audio

No

Image sensor

1/3\" 2MP CMOS SONY323
High Performance CMOS

Minimum illumination

0 Lux / EXIR IR (20 m)
0.1 Lux (colour) / 0.01 Lux (B/N)

Basic functions

OSD menu, Day/Night with IR-CUT (ICR)

Configurable OSD functions

DWDR, BLC, HLC, 2D-NR, AWB, AGC, Smart IR

Lens

6.0 mm
Varifocal 4.7~94.0 mm (Optical Zoom 20X)
Varifocal 4.7~94.0 mm (Zoom óptico 20X)

Day / Night

Removable mechanical ICR filter

Pan/Tilt Range

Horizontal: 0°~360°, Vertical: 0°~93° auto flip 180°

Manual speed

Horizontal: 0° ~ 80° /s, Vertical: 0° ~ 40° /s
Horizontal: 0° ~ 80°/sec, Vertical: 0° ~ 40°/sec

Preset positions

220 preset, 1 auto tour, auto pan, auto scan

Alarms

No

Motion Detection

Si dispone
Yes, it is available

Weight (without support)

2.8 kg

Gain Control

Auto / Manual

Backlight compensation

BLC, DWDR, AWB, AGC, 2D-NR

S/N ratio

≥50 dB

Dimensions (without bracket)

250 mm (H) x 120 (Ø) mm

Weight (without bracket)

2.8 kg
