Data sheet

Weight

2200 g

Power

Lithium Battery 3.7V / 5000mAh Rechargeable

Grado de protección

-

Temp. operation

15º C ~ + 30º C

Degree of protection

-

Dimensions

86 (Fo) x 236 (Al) x 75.5(An) mm
86(D) x 236(W) x 75.5(An)mm

Power supply

Lithium Battery 3.7V / 5000mAh Rechargeable

Communication

USB Type C (for battery charging)

Internal memory

Micro SD card up to 16 GB (included)

Battery duration

6 hours

Display

2.8\" TFT LCD Display (320x240)

Installation

Tripod (Not included) or handheld

Intelligent functions

Temperature measurement

Thermal sensor

80x60 Vox

Spectral range

8~14um

Measurement range

30ºC ~ 45ºC

Accuracy

± 0.5ºC

Field of view (thermal)

51º x 38º

Thermal sensitivity (NETD)

≤ 150mK

Usage Modes

Center Point, Measurement of Maximum and Minimum Temperature Point
Center point, Maximum and minimum temperature measurement, ROI function

Image Modes

Thermal

Image captures

Manual (trigger)
Manual (trigger) / Automatic (in case of alarm)
Manual (trigger) / Automatic in case of alarm (On the MicroSD)

Light / Flashlight

Manual activation / Activation due to increase or decrease in temperature

PC Software

Live Image, Event History, Audible Alarm Notification

Notification

Sound: Buzzer on the device itself / Visual: On the camera display
Sound: Buzzer on the device itself or PC software / Visual: On the camera display or in PC software

Languages

Spanish, English, Portuguese, Italian, German, French, Chinese
