VIGI IP Camera C230I Mini Dome 3MP Plastic IR 2.8


Brand VIGI
Model C230I Mini(2.8mm)
Camera - Image Sensor: 1/2.8” Progressive Scan CMOS
- Shutter speed: 1/3 to 1/10000 s
- Slow shutter
- Minimum illumination: Color: 0.01 lux; 0 Lux with IR light
- Day/night mechanism: IR Cut Filter
- Day/Night Switch: Unified/Scheduled/Auto
Lens - Type Fixed focal lens
- Focal length: 2.8 mm
- Aperture: F21.6
- FOV:
Horizontal FOV: 106.9º
Vertical FOV: 56.9°
Diagonal FOV: 127.9°
- Lens mount: M12
- DORI Distance
Detection: 49 m
Observe: 20 m
Recognize: 10 m
Identify: 5 m
Lightning
- Number of infrared LEDs: 2
Range: 30m
Wavelength: 850 nm
- Lighting control on/off: Automatic/Scheduled/Always on/Always off
Image and Video Image
- Image settings:
Mirror
Glow
Contrast
Saturation
Sharpness
Exposure
WDR
White balance
Avoid overexposure to infrared light
HLC adjustable via client software
Rotation (90°/270°)
- Image enhancement: BLC/3D DNR/HLC/SmartIR
- Wide dynamic range: DWDR
- SNR: ≥ 52 dB
- Image parameter switch
- Privacy Mask: Up to 4 masks
- ROI: 1 Region
- OSD Configuration
Video
- Max. Resolution: 2304 × 1296
- Main Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Main Stream Resolution:
2304x1296
2048x1280
1920x1080
1280x720
- Sub-Stream Frame Rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
- Sub-Stream Resolution: 704x576, 640x480, 352x288, 320x240
- Bit rate control: CBR, VBR
- Video compression:
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264
- H.264 Type: Main Profile/High Profile
- H.264+: Main Stream compatible
- H.264 Type: Main Profile/High Profile
- H.265 Type: Main profile
- H.265+: Main Stream compatible
- Main Stream Video Bitrate: 256 Kbps to 4 Mbps
- Sub-Stream Video Bit Rate: 64 Kbps to 512 Kbps
Interfaces - Network Interface: 1 x RJ45 10/100M Self-Adaptive Ethernet Port, PoE
- Reset button
- Power: DC port
- Reset button
- Internal storage: Built-in memory card slot, supports MicroSD card up to 256GB
- Built-in microphone
- Built-in speaker
- Audio
Characteristics Grid
- Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
- ONVIF
- API: ONVIF
- Simultaneous live view of 3 main streams and 3 substreams
- Client: VIGI App, VIGI Security Manager, VIGI NVR, Web
- Web browser: Open Network Video Interface (Profile S)
- Security: Password protection, HTTPS encryption, IP address filtering, Digest authentication
Alarm and Event Management
- Intelligent:
Classification of people and vehicles
Area intrusion detection
Line crossing detection
People detection
Vehicle detection
Region Entry Detection
Region Exit Detection
Detection of abandoned objects
Object Removal Detection
- Basic: Motion detection, video tampering detection, exception (illegal login)
- Alarm linkage: Video recording with memory card, message sending, audible warning
- Push exit notification message
Feeding
- Energy consumption
12V DC: Max. 5W
PoE: Class 0
- Power supply
12 V DC ± 5 %
5.5mm coaxial power plug
PoE (802.3af/at, class 0)
Dimensions and weight
- 114 × 114 × 58 mm
- 0.23 kg
Contains
- VIGI network camera
- Quick Start Guide
- Mounting accessories
- Mounting template
