Network Termination Registration for Data/Coaxial/Telephone/Fiber Televes
Designed to house the equipment separating the user's network from the community's. Specified to meet the ICT2 requirements and designed to be placed in the NTE, it works as a enclosure that houses the different technologies; can be manipulated by the user.
€212.36
€326.70
Save 35%
Tax included
Reference
televes-546702
Brand
Televes
Network Termination Registration for Data/Coaxial/Telephone/Fiber Televes
€212.36
€326.70
Save 35%
You might also like
Data/Coaxial/fibre Terminal Enclousure (RTR). Coaxial, data, telephone and optical fibre cable.
Designed to house the equipment separating the user's network from the community's. Specified to meet the ICT2 requirements and designed to be placed in the NTE, it works as a enclosure that houses the different technologies; can be manipulated by the user.
Highlights
- Robust: made of steel.
- Pre-marked inputs for an easy opening: 16 inputs for 32mm-tube and 16 inputs for 20mm-tube
- Perforated door for better ventilation with an ABS locking tab (can be manually operated by the user)
Features
- Lacquered white
- Equipped with a lock to avoid external manipulation
- Interchangeable door (left or right hinge)
- MDF board for product bolting (dimensions: 520x420x12mm)
- Chassis with lateral tabs that allows its fixing on the wall while the mortar is being applied
- Includes a ground connection between the door and the chassis
Specifications
| Registro / Register | Material | armazón / framework + marco / frame | Acero / Steel |
| Tablero interior / Interior board | Tablero de fibras de densidad media / Medium Density Fibreboard (MDF | ||
| Espesor material / Material thickness | armazón / framework & marco / frame (mm) | 1.5 ± 0.2 | |
| Dimensiones / Dimensions (X, Y, Z) | armazón / framework (mm) | 600 x 500 x 80 | |
| armazón / framework & marco / frame (mm) | 640 x 530 x 85 | ||
| Tablero interior / Interior board (mm) | 520 x 420 x 12 | ||
| Color | RAL | 9010 | |
| Acceso para tubos / Pipe access | Ø 32 mm | 16 | |
| Ø 20 mm | 16 | ||
| Ubicación / Location | Interior / Inner | ||
| Fijación / Fixation | tipo / type | Encastrada / Embebed | |
| Carga máxima / Max. load | kg/m3 | 200 | |
| Disipación térmica / Thermal disipation | W | 28 | |
| Toma de tierra / Grounding | Si / Yes | ||
| Peso / Weight | g | 8000 ± 5% | |
| Estándar / Standard | EN 62208 |
