TAS 2401 amplifier Amplifier 2 IF (G 40) + Terr (step) output 120 dBμV
TAS 2401 is a head-end amplifier designed for ICT installations. It has three inputs, two SAT with independent amplification circuits (40 dB) and one Terrestrial (passive), and two outputs (SAT1 + Terr. / SAT2 + Terr.).
€1,123.64
Tax included
Reference
triax-360418
Brand
Triax
TAS 2401 amplifier Amplifier 2 IF (G 40) + Terr (step) output 120 dBμV
€1,123.64
TAS 2401 is a head-end amplifier designed for ICT installations. It has three inputs, two SAT with independent amplification circuits (40 dB) and one Terrestrial (passive), and two outputs (SAT1 + Terr. / SAT2 + Terr.).
It has 6 highly selective adjustable filters, which allow it to respond to all installations where there are a large number of channels.
Specifications
| Model | TAS 2401 | |
| Code | 360418 | |
| Number of entries | 3 (SAT1, SAT2, TV) | |
| Number of outputs | 2 (SAT1 + TV, SAT2 + TV)) | |
| Frequency range |
TV: 45 - 860 SAT: 950-2400 |
|
|
Gain TV (Terrestrial) SAT 1 SAT 2 |
-5 35 - 40 (slope 5dB) 35 - 40 (slope 5dB) |
|
| Attenuation | 0 - 20 | |
| Equalization | - | |
|
Output level DIN EN50083-5, 34 dB IMA 3. Ord |
2 x 118 | |
| Uncoupling Terr. / SAT | 35 | |
| Noise Figure | 6 | |
| Feeding | 12 to 24 | |
| Consumption | 260 | |
| LNB power | 12 V / max. 400 mA | |
| Connectors | "F" Female | |
| Impedance | 75 | |
| Dimensions | 225 x 65 x 30 |
Chassis placement example
TAS 2401 is a head-end amplifier designed for ICT installations. It has three inputs, two SAT with independent amplification circuits (40 dB) and one Terrestrial (passive), and two outputs (SAT1 + Terr. / SAT2 + Terr.).
