Data sheet

Weight

800 g

Power

DC 12V / 0.65A, max. 7.8W, PoE IEEE802.3af max. 8.8W

Temp. operation

-30º C ~ +60º C

Degree of protection

IP66

Dimensions

124.5(Al) x 138.3(Ø) mm

Transfer Rate

32 Kbps ~ 8 Mbps

Operating temperature

5–40 °C

Power supply

100–240 VCA, 50/60 Hz

Material

Metallic

Video output

XGA – Multiple matrix views

Audio

1 IN / 1 OUT Microphone and speaker built-in

Audio output

Standard: 1 line output. Optional: up to 1 per camera via audio switcher. Audio output on IP cameras (depending on the camera) with ONVIF Profile S/T controller

Humidity

from 20-93 % RH non-condensing

Operating system

ADPRO® XO™ Security operating system, based on Linux

Management

Web client interface (XO client), ADPRO VideoCentral Platinum, third-party software (SDK available) and iTrace App for iOS/Android

Relay outputs

8 outputs on the box (SPDT) + 8 outputs (SPDT) with USB XO I/O interface module + 128 outputs (SPDT) with Net I/O module with PoE

Image sensor

1/2.7\" Progressive Scan CMOS

Minimum illumination

0.003 Lux / F1.4 Ultra Low Light Color

Lens

2.8 mm (H:103º, V: 55º)

Maximum resolution

4 Megapixel (2688x1520)

Infrared lighting

0 Lux / IR LEDs (30 m)

Image improvements

WDR (120dB), BLC, 3D-DNR, MD, ROI

Day / Night

Removable mechanical ICR filter

Base dimensions

88 x 88 x 88 mm (3 screws)

Alarms

1 IN / 1 RELAY (max). 12VDC, 30mA)

Internal memory

MicroSD card, Max 256 GB

Remote access

NVR, Web Browser, App Smartphone and PC Software Safire Control Center

Main Stream rate

4Mpx / 3Mpx / 1080p / 720p (1 ~ 25 FPS)

Extra Stream rate

640x480, 640x360, 320x240 (1 ~ 25 FPS)

Compression

H.265+ / H265 /H.264+ / H264

Network interface

Ethernet 10/100 BaseT

Video Resolution

Up to HD/MP resolution (Depending on the camera)

Video analysis

Basic motion detection (VMD), camera sabotage detection. Up to 16 analysis channels IntrusionTrace™ and LoiterTrace™ (datasheets available separately)

Interoperability

ONVIF

People counting

YES, 95% Precision (Compatible with the firmware V5.5.131 build version 200702) TrueSense, Face capture and People Counting cannot be active at the same time

Ethernet

2 x 100/1000BASE-T, autodetection, full duplex, RJ45

Video compression

H.264/H.265 (H.265 supported with ONVIF profile S/T, Hikvision and generic drivers)

Advanced features

Line-crossing detection | intrusion | entry / exit area

Video input

1–32 IP cameras (For optimal performance, disable monitor output when using more than 16 IP cameras)

Audio input

Supports built-in audio input (Depending on the camera)

Images/second

Full HD @25/30 ips – Megapixels: ips is depending on the camera

Bandwidth Capacity

32 x 5 Mbps

Bandwidth Management

Configurable bitrate constant or variable / Configurable bandwidth limiter

Command inputs

20 inputs in the box (monitored) + 20 inputs (monitored) with USB XO I/O interface module + 128 with Net I/O module with PoE

Web server

XO Client - Integrated Web Client Application (ActiveX)

Recording Type

Schedule / Detection / Event

IP Camera Integration

Brand-specific, generic or with driver ONVIF S/T profile (Depends on the camera)

Disk Capacity

Max. 4 x SATA 10 TB HDD. Compatibility with RAID 1. 2 Identical HDD)

Warranty

2 years

Dimensions (W x H x L)

441 x 88 x 305 mm

Mobile Apps

iTrace, iPIR

Truesense 2

Motion Detection, Line Crossing, Entry / Exit area TrueSense, Face capture and People Counting cannot be active at the same time

Face Capture

YES (Compatible with Safire\'s Face Recognition recorders) TrueSense, Face capture and People Counting cannot be active at the same time

Mask Detection

YES (Compatible with the firmware V5.5.131 build version 200702) People Counting and Mask Detection use different firmware files
