Uniview Pro UV-NVR516-128 - NVR for IP cameras, Pro range, 128 CH video | 12 Mpx,…
NVR for IP cameras - Pro range - 128 CH video | 12 Mpx - Supports 2 decoder cards - Bandwidth 512 Mbps - Supports 16 hard drives | RAID
€3,530.00
Tax included
Reference
UV-NVR516-128
Brand
Uniview Pro
Uniview Pro UV-NVR516-128 - NVR for IP cameras, Pro range, 128 CH video | 12 Mpx,…
€3,530.00
You might also like
- Uniview
- NVR for IP cameras
- Pro range
- 128 CH
- 512 Mbps bandwidth supported
- Maximum resolution 12 Megapixel
- Compression Ultra265/H.265/H.264
- Intelligent functions
- Alarms
- Audio
- Output 2 x HDMI 4K and VGA
- Supports 2 decoder cards
- Space for 16 HDD
- Up to 48 HDD using 2 miniSAS ports
- RAID function 0/1/5/6/10/50/60
- Output DC 12 V
- Redundant power supply (optional)
- Mouse
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
Features
- NVR for IP cameras
- Pro range
- 128 CH video | 12 Mpx
- Supports 2 decoder cards
- Bandwidth 512 Mbps
- Supports 16 hard drives | RAID
Specs
| Brand | Uniview |
| Range | Pro |
| Inputs for IP cameras | LAN port up to 512 channels |
| IP compatible cameras | UNIVIEW, ONVIF |
| Video outputs | 2 HDMI 4K, 1 VGA | Supports 2 decoder cards 6 x HDMI |
| Video compression format | Ultra265 / H.265 / H.264 |
| Display resolution | 3840x2160, 1920x1080, 1600x1200 1280x1024, 1280x720, 1024x768 |
| Total bandwidth | 512 Mbps downstream / 384 Mbps upstream |
| Main Stream recording | 12Mpx / 8Mpx / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 720p / D1 / 2CIF / CIF |
| Bidirectional audio | 1 input / 1 BNC output |
| Alarms | 24 inputs / 8 relay |
| Recording method | Manual, programmed, motion detection |
| Intelligent functions | People Counting, Face Detection, Human Body Detection, Intrusion Detection, Line Crossing, Audio Detection, Scene Change, Blur Detection, Auto Tracking, Object Removed, Object Left Behind |
| Internal memory | 16 SATA HDD 3.5" up to 10 TB (not included) | 1 x eSATA | 2 x miniSAS |
| Storage technology |
RAID function 0/1/5/6/10/50/60 and Hot Spare function N+1 |
| Communication | 4 x USB 3.0 / 4 x RJ45 (Ethernet) / 2 x 1000M SFP / 1 x RS232 / 1 x RS485 |
| Remote access | Web Browser, CMS Software (EZStation), Smartphone (EZView/EZLive) |
| Power | AC 100 ~ 240V (Redundant power supply optional) | DC output 12V |
| Dimensions / Weight | 131 (H) x 477 (F) x 482 (W) mm / ≤10 Kg (Rack 19" 3U) |
Package content
- Uniview NVR
- Mouse
- Power supply cable
Data sheet
- Weight
- 52 g
820 g - Power
- 1 x battery (R6) 3.6V
- Degree of protection
- IP67
- Dimensions
- 103 (Al) x 71 (An) x 47 (Fo) mm
122 (H) x 30 (W) x 22.4 (D) mm - Nominal voltage
- 12 V
- Nominal capacity
- 2.3 Ah (20HR)
- Standby use
- 13.5 ~ 13.8 V
- Cyclic use
- 14.4 ~ 14.8 V
- Initial intensity
- ≥0.7 A
- Maximum discharge intensity
- 34.5 A max.
- Internal resistance
- 70 MΩ
- Connection type
- F1
- Interface
- USB
- Temperature measurement range
- -40ºC~80ºC
-40ºC~1000ºC±(1%+3) - Data storage
- Up to 60.000
- Accuracy
- Temperature: 0ºC~40ºC±(0.5ºC),-30ºC~0ºC /40ºC~70ºC ±(1ºC),-40ºC~-30ºC / 70ºC~80ºC ±(2ºC) Relative humidity: 20%RH~80%RH±(3%RH),＜20%RH or ＞80%RH ±(5%RH)
- Temperature display resolution
- 0.1ºC
- Relative humidity measuring range
- 0%RH~100%RH
- Display resolution relative humidity
- 0.1%RH
- Data recovery
- Yes, it has
- Alarm threshold
- Yes, it has
NVR for IP cameras - Pro range - 128 CH video | 12 Mpx - Supports 2 decoder cards - Bandwidth 512 Mbps - Supports 16 hard drives | RAID
