Kilsen KFP-AF2-S-09 Analog control unit -small box- with 2 loops

Analog control unit -small box- with 2 loops

• 2-loop analogue fire panel with up to 128 zones.
• Up to 24 zone indicator LEDs for Fire and Fault with ample > space for text.
• Auto configuration and regional operating modes adjustable by > default.
• TCP/IP Ethernet port for remote programming and maintenance.
• Graphic LCD according to EN54 with icons.
• Jog Dial with 4 buttons for simple and intuitive user control.
• Pleasant design aesthetic with paintable synthetic door.
• Easily removable door and chassis for a quick and clean installation.
• All pluggable connectors.
• 3 USB ports for storage drives.
• 3 RS232 ports.
• 24VDC auxiliary output, supports reset.
• Menu structure for 3 operator levels.
• Record in memory of 9999 events.
• Capacity: Max. 2 x 12V/7.2Ah (use supplied cables).
• Up to 72 hours of standby operation and 30 minutes in alarm.
• Compatible with KL700A series of detectors with replaceable > optical camera and loop powered sounders and sounder bases.
• Physical Dimensions: 410 x 298 x 162mm (W x H x D).
• Net weight: 5.2 kg (without battery).
