Data sheet

Weight

2.5Kg

Detection range

25~40mm

Frequency

433MHz

LEDs indication

Alarm

Battery

1 x CR123A 3V

Temp. operation

-10º C ~ 50º C

Degree of protection

Interior

Dimensions

84(Al) x 39 (W) x 22 (D) mm
85 x 85 x 54 mm (H x W x D)
370 x 410 x 80 mm

Temperature

-5ºC~+45ºC

Range

Up to 150m

IP protection

IP21

Primary power supply

Switching source 187-252V AC 50-60 Hz 65W max.

Backup power supply

2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.

Number of zones

16 zones, up to 30 detectors by area.

Siren outputs

2 siren outputs 24VDC. Independent and monitored open collector outputs

Relay outputs

8 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.

End of line resistance

Areas fully monitored by end-of-line resistance (4.7K)

Auxiliary Output Voltage

24VDC. Protected by resettable electronic fuse 1.85A

Protection Index

IP30

Material and colour

ABS, colour: White

Recommended cable

Fire cable with a minimum section of 1.0mm (18AWG).

Tamper

Device and wall

Certification

EN 54-11

Voltage DC

Nominal Relay Switching current 24V (15~40V)

Available languages

Spanish, English, Portuguese, Italian, French, and German.

Operating temperature range

-30ºC ~ +70ºC

Humidity (non condensing)

95% RH

Average consumption

70μA

LED Current Consumption

6mA@24VDC
