Ikusi CTO-048 Multi-operator box 48 SC/APC ports (Oper/Client Space) 450x180x150 mm

Box designed for the interconnection of the Operator's network with the connections to customers in an indoor installation.

€114.60
Tax included
Reference ikusi-8293
Brand Ikusi
Quantity
Available Now

Free shipping
Dahua NVR2108-I NVR IP Dahua de 8 canales 4K/8MP

Ikusi CTO-048 Multi-operator box 48 SC/APC ports (Oper/Client Space) 450x180x150 mm

€114.60

Boxes designed for the interconnection of the Operator network with the connections to customers in an indoor installation.

The box has 2 separate spaces with independent doors for the Operator and Customer area. In the operator area, in addition to the fixings for the fiber input cables, there are spaces to house optical distributors in BXM type tablets, fusion trays and fiber organizers.

Between both areas is the separator where the SC / LCdx type adapters are located.

In the customer area, there are elements to fix the connection cables that will leave the box towards the customers through the space left by the lower or upper cover once the one that is most convenient in each case is removed.

These boxes are easily stackable to increase their capacity and facilitate customer interconnectivity between Operators.

Made of highly resistant polycarbonate with a careful design and very easy installation.

They are supplied with all the necessary accessories.

Specifications

Model CTO-048
Ref. 8293

Number of entries

Measure

4

≤ Ø16 mm
port 48 SC / LCdx

Trays:

- Number

- Material

- Max. fiber optic fusion (double layer)

6

ABS - UL 94V-0

96
IP 55
Protection against mechanical impacts IK05 (5 J)

Splitters (not included):

- Capacity

- Measurements

3

45x100x10 mm (SOP-BXM model)
Static charge 1000 N
Operating temperature -5º to + 60ºC
Dimensions 180x450x150
Weight 2.60 kg
Color Gray

Accessories

  • Marking template
  • Triangle key
  • Plastic ties (25 units)
  • Cable thickeners (1 pc)
  • Foam Tape (40 cm)
  • Fixing parts between boxes
