DSX-602 Network Certifier Cat-6A (With channel adapters) Televes
The DSX-602 is an indispensable certification tool for the analysis of twisted pair networks. Ranging from Cat 3 / Class C to Cat 6A / Class E, it offers speed and reliability to make your work more efficient and productive. No other tester will offer you as much consistency as the DSX-602.
€353.90
€544.46
Save 35%
Tax included
Reference
televes-236705
Brand
Televes
DSX-602 Network Certifier Cat-6A (With channel adapters) Televes
€353.90
€544.46
Save 35%
Cable network certifier. 2 channel adapters
Speed and reliability
The DSX-602 is an indispensable certification tool for the analysis of twisted pair networks. Ranging from Cat 3 / Class C to Cat 6A / Class E, it offers speed and reliability to make your work more efficient and productive. No other tester will offer you as much consistency as the DSX-602.
Stands out for
- Up to 500 MHz frequency range certifying Cat 6A / Class EA cabling for 10 Gigabit Ethernet in as little as 10 seconds
- Advanced diagnostics feature that detects fault location and suggests corrective action
- LinkWare ™ Live service (cloud-based), allowing certification jobs to be managed anytime, from anywhere, by anyone, on any device
- 5.7 ”LCD capacitive touch screen
- Gesture user interface
- Storage capacity of up to 12,000 Cat-6A test results with charts
Characteristics
- Wiremap analysis, length, propagation delay, delay difference, DC loop resistance, insertion loss, return loss (RL), near end crosstalk (NEXT), attenuation / crosstalk ratio (ACR-N) , ACR-F (ELFEXT), Power Sum ACR-F (PS ELFEXT), Power Sum NEXT, Power Sum ACR-N
- Great robustness of the equipment
- Long battery life (8 hours of continuous work)
- Lightness (Only 1.36Kg of weight)
- Transport case
- Lithium-ion batteries
Specifications
| Test standards | |
| AUNT | Category 3, 5, 5e, 6, 6A according to TIA 568-C.2 or TIA-1005 |
| ISO / IEC | Certification of Classes C and D, E, EA according to ISO / IEC 11801: 2002 standards and their corresponding amendments |
| IEEE 802.3 | 10BASE-T, 100BASE-TX, 1000BASE-T, 10GBASE-T |
| UNE / IN | Certification of Classes C and D, E, EA, according to the standards UNE-EN 50173-1: 2011 (ICT2) |
| General specifications | |
| Automatic check speed | Category 5e or 6 / Class D or E full bi-directional auto test: 9 seconds Full Category 6A / Class EA Bi-Directional Self Test: 10 seconds |
| Supported test parameters (the standard determines the parameters and the frequency range to consider) |
Wiremap, Length, Propagation Delay, Delay Difference, DC Loop Resistance, Insertion Loss (Attenuation), Return Loss (RL), Near End Crosstalk (NEXT), Ratio attenuation / crosstalk (ACR-N), ACR-F (ELFEXT), Power Sum ACR-F (PS ELFEXT), Power Sum NEXT, Power Sum ACR-N |
| Maximum frequency | 500 MHz |
| Storage of Test Results | 12000 (Cat-6A with graphics) |
| Screen | 5.7 ”LCD screen with projected capacitive touch screen |
| Drums | Lithium-ion (7.2V) |
| Battery duration | 8 hours on average |
| Battery Charge Time | 4 hours (below 40 ° C with tester off) |
| Operating temperature | 0 ° C to 45 ° C (32 ° F to 113 ° F) |
| Storage temperature | -20 ° C to +60 ° C (-4 ° F to +140 ° F) |
| Operating relative humidity (% RH non-condensing) |
32 ° F to 95 ° F (0 ° C to 35 ° C): 0% to 90% 95 ° F to 113 ° F (35 ° C to 45 ° C): 0% to 70% |
| Vibration | Random, 2g, 5Hz to 500Hz |
| Knock | 1m drop tests with and without module and adapter included |
| Security | CSA 22.2 No. 61010, IEC 61010-1 3rd Edition |
| Altitude | 4,000 m (13,123 ft) 3,200 m (10,500 ft) with AC adapter |
| EMC | EN 61326-1: Portable |
Application example
Data sheet
- Weight
- 1760 g
- Power
- 12VDC, PoE IEEE802.3af
- Temp. operation
- -40º C ~ +65º C
- Degree of protection
- Weatherproof IP66
- Dimensions
- 358.3 mm (Fo) x 115.2 (An) x 115 (Al) mm
- Alarm
- 2 / 2 In / Relay
- Audio
- 1 Input / 1 line level output 600 ohm
- Lens
- 3.1 mm (Therm) / 4 mm (Opt)
- Viewing angle
- 50°×37.2° (Term) / 84°×44.8° (Opt)
- Internal memory
- Micro SD card up to 256GB
- Remote access
- WEB, CMS (DSS/PSS), Smartphone and NVR interface
- Main Stream rate
- 1280x720(25fps) Thermal / 2688x1520 (25fps) Optical
- Extra Stream rate
- 704x576 (25fps) Thermal / 704x576 (25fps) Optical
- Compression
- H.265 / H.264 / MJPEG
- Network interface
- Ethernet 10/100 BaseT
- Interoperability
- ONVIF
- Intelligent functions
- Fire detection and alarm, line crossover, intrusion, abandoned/lost object
- Thermal sensor
- 160x120 Vanadium oxide
- Optical sensor
- 1/2.7” Progressive Scan CMOS 4 Megapixel
- Range performance
- Human: 91 (Detection) / 23 (Recognition) / 11 (Identification) m Vehicle: 280 (Detection) / 70 (Recognition) / 35 (Identification) m
- VCA ranges
- Human: 15 m Vehicle: 43 m Tº measurement (2x2m): 66 m Tº measurement (1x1m): 33 m Fire detection (2x2m): 180 m Fire detection (1x1m): 90 m
- Thermal sensitivity
- ≤ 40mK (0.05 º C)
- Thermal measurement range
- -20 ~150 º C / ± 8 º C
- Spectral range
- 8~14μm
- Pitch detector
- 17μm
- VCA
- Up to 8 VCA rules (linecrossing, intrusion, entry and exit of area)
- Temperature rules
- Up to 21 rules (10 points, 10 areas y 1 line)
