Triax D5A 11 W Directional antenna for 4G/5G signal reception (G11 dBi) Includes 7 meter cable White
Directional antenna for 4G/5G signal reception. Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach. Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location.
€131.38
Tax included
Reference
triax-109601
Brand
Triax
Triax D5A 11 W Directional antenna for 4G/5G signal reception (G11 dBi) Includes 7 meter cable White
€131.38
Directional antenna for 4G/5G signal reception.
Future-proof connectivity, wherever you are
Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach.
Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location. The 11 dB gain ensures outstanding signal quality.
The antennas are ready for the advancing 5G roll-out across Scandinavia, bringing speeds up to 100x faster than 4G. They are fully compatible with all mobile signals: use the best possible 4G LTE speeds now, with no need for future upgrades when 5G arrives.
For the ultimate in speed and reliability, our antennas are MIMO compatible. We recommend installing a pair of directional antennas 70 cm apart and at 45° opposing angles.
The antenna is delivered with 7m white cable with connector, which is ready for mounting directly on the router.
Specifications
| CHARACTERISTICS | |
|---|---|
| Antenna type | directional |
| Antenna use | outdoor |
| Polarization | vertical or horizontal |
| MIMO | Yes by the use of 2 antennas |
| FREQUENCY | |
| Frequency range | 698-960/1710-2700/3300-3600/4800-5000 MHz |
| Services | GMS/Wi-Fi/3G/4G/LTE/5G - (5G low band) |
| GAIN | |
| Gain | 10...11 dBi |
| VSWR | < 2.5 |
| ELECTRICAL | |
| Front to back ratio - horizontal | > 21 dB |
| Impedance | 50 Ω |
| OPERATIONAL | |
| IP rating | 65 |
| Lightning protection | DC ground on the antenna |
| Temperature - operating | -40... +60 °C |
| CONNECTORS | |
| Connector Type | SMA-male |
| Output cable type | PVC white UV protected low loss coaxial cable |
| MECHANICAL | |
| Beamwidth horizontal | 60 ° |
| Beamwidth vertical | 55 ° |
| Diameter of installation pole | 30-53 mm |
| Bracketry | with wingnuts |
| Main material | Plastic housing ABS |
| Colour | RAL 1013 - White |
| Packing QTY | 1 |
| Product Height | 210 mm |
| Product Length | 445 mm |
| Product Depth | 70 mm |
| Packaging Height | 0,568 m |
| Packaging Width | 0,217 m |
| Packaging Depth | 0,087 m |
| Packaging Volume | 0,011 m3 |
| Net Weight | 1,180 kg |
| Tara Weight | 0,235 kg |
| Total Weight | 1,415 kg |
