Triax O5A 06W Omni-directional antenna for 4G/5G signal reception (G5 dBi) Includes two 2-meter white cables
360° antenna for 4G/5G signal reception. Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach. Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location.
€13.02
Tax included
Reference
triax-109602
Brand
Triax
Triax O5A 06W Omni-directional antenna for 4G/5G signal reception (G5 dBi) Includes two 2-meter white cables
€13.02
360° antenna for 4G/5G signal reception.
Future-proof connectivity, wherever you are
Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach.
Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location.
The antennas are ready for the advancing 5G roll-out across Scandinavia, bringing speeds up to 100x faster than 4G. They are fully compatible with all mobile signals: use the best possible 4G LTE speeds now, with no need for future upgrades when 5G arrives.
For the ultimate in speed and reliability, our antennas are MIMO compatible.
The antenna is delivered with 2m white twin cable with connectors, which are ready for mounting directly on the 2 antenna inputs on the router.
Specifications
| CHARACTERISTICS | |
|---|---|
| Antenna type | omnidirectional |
| Antenna use | indoor & outdoor |
| Polarization | Antenna 1 - horizontal Antenna 2 - vertical |
| MIMO | Yes |
| FREQUENCY | |
| Frequency range | 698-960/1710-2700/3300-3600/4800-5000 MHz |
| Services | GMS/Wi-Fi/3G/4G/LTE/5G - (5G low band) |
| GAIN | |
| Gain | 4...6 dBi |
| VSWR | 3 |
| ELECTRICAL | |
| Front to back ratio - horizontal | > 21 dB |
| Impedance | 50 Ω |
| OPERATIONAL | |
| IP rating | 65 |
| Lightning protection | DC ground on the antenna |
| Temperature - operating | -40... +60 °C |
| CONNECTORS | |
| Connector Type | 2 x SMA-male |
| Output cable type | PVC white UV protected low loss coaxial cable |
| MECHANICAL | |
| Beamwidth horizontal | 360 ° |
| Beamwidth vertical | 120 ° |
| Diameter of installation pole | 30-53 mm |
| Bracketry | with wingnuts |
| Main material | Plastic housing ABS |
| Colour | RAL 1013 - White |
| Packing QTY | 1 |
| Product Height | 200 mm |
| Product Length | 215 mm |
| Product Depth | 70 mm |
| Packaging Height | 0,223 m |
| Packaging Width | 0,221 m |
| Packaging Depth | 0,089 m |
| Packaging Volume | 0,004 m3 |
| Net Weight | 0,750 kg |
| Tara Weight | 0,140 kg |
| Total Weight | 0,890 kg |
Data sheet
- Power
- DC 48 V
- Dimensions / Weight
- 47(Al) x 260(An) x 240 (Fo) mm / 1Kg
- Range
- Easy
- Communication
- 1 x USB 2.0 / 1 x USB 3.0 / 1 x RJ45 (Ethernet)
- Inputs for IP cameras
- LAN port up to 4 channels
- IP compatible cameras
- UNIVIEW, ONVIF
- Bidirectional audio
- 1 input / 1 RCA output
- Video compression format
- Ultra 265 / H.265 / H.264
- Display resolution
- 3840x2160, 1920x1080, 1600x1200, 1280x1024, 1280x720, 1024x768
- Total bandwidth
- 80 Mbps downstream / 64 Mbps upstream
- Main Stream recording
- 4K / 5Mpx 4Mpx 3Mpx / 1080p / 960p 720p / D12CIF / CIF
- Recording method
- Manual, programmed, motion detection
- External Backup
- USB / HDD USB memory
- Internal memory
- 1 SATA HDD 3.5\" of up to 6 TB (not included)
- Remote access
- Web browser, Safire Control Center Smartphone App and PC Software
- Video outputs
- 1 HDMI 4K, 1 VGA
- Intelligent functions
- People Counting, Face Detection, Intrusion Detection, Line Crossing, Scene Change, Audio Detection, Blur Detection, Auto Tracking, Object Removed, Object Left Behind
- Power over Ethernet
- Switch from 4 PoE ports IEEE802.3at (max.54 W, 30 on a single port)
- Decoding
- 1x4K @ 30fps / 1x5MPx @ 30fps / 2x4MPx @ 30fps / 2x3MPx @ 30fps / 4x1080p @ 30fps
360° antenna for 4G/5G signal reception. Work, rest or play online reliably and quickly, wherever you’re staying – TRIAX 5G antennas boost mobile broadband reception in places fibre doesn’t reach. Simply connect to your choice of mobile broadband router to receive the maximum attainable mobile network speed at each location.
