Dmtech DMT-FP9000R - DMTECH Control Repeater, 2 Siren output, 2 alarm and…
DMTECH Control Repeater - 2 Siren output - 2 alarm and fault outputs and 2 configurable relay outputs - Allows up to 8 stations to be connected - Necessary module DMT-M9000-485 - LCD screen and advanced programming menu
€149.50
€230.00
Save 35%
Tax included
Reference
DMT-FP9000R
Brand
Dmtech
Dmtech DMT-FP9000R - DMTECH Control Repeater, 2 Siren output, 2 alarm and…
€149.50
€230.00
Save 35%
- DMTECH
- Remote control terminal
- Built-in keypad with mute, view, enable/disable, test buttons, resound, system reset
- Allows to see all the information of the installation
- Up to 8 stations connected
- Necessary module DMT-M9000-485
- 230V AC operating voltage
- Capacity for 2 12V batteries
Features
- DMTECH Control Repeater
- 2 Siren output
- 2 alarm and fault outputs and 2 configurable relay outputs
- Allows up to 8 stations to be connected
- Necessary module DMT-M9000-485
- LCD screen and advanced programming menu
Specs
| Primary power supply | Switching source 187-252V AC 50-60 Hz 65W max. |
| Backup power supply | 2 batteries 12VDC (up to 7.2 Ah). Ensures minimum 72 hours duration. |
| Available languages | English, French, Spanish, Turkish, Romanian and Russian. |
| Siren outputs | 2 siren outputs 24VDC. Independent and monitored open collector outputs |
| Relay outputs | 4 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max. |
| End of line resistance | Areas fully monitored by end-of-line resistance (4.7K) |
| Auxiliary Output Voltage | 24VDC. Protected by resettable electronic fuse 1.85A |
| Protection Index | IP30 |
| Temperature | -5ºC~+45ºC |
| Material and colour | ABS, colour: White |
| Dimensions | 310 x 240 x 80 mm |
| Weight | 1,3Kg |
| Recommended cable | Fire cable with a minimum section of 1.0mm (18AWG). |
Package content
- Remote control terminal
- Battery cables
- Fusible
Data sheet
- Weight
- 1,3Kg
- Dimensions
- 310 x 240 x 80 mm
- Temperature
- -5ºC~+45ºC
- Primary power supply
- Fuente conmutada 187-252V AC 50-60 Hz 65W max.
Switching source 187-252V AC 50-60 Hz 65W max. - Backup power supply
- 2 batteries 12VDC (up to 7.2 Ah). Ensures minimum 72 hours duration.
- Siren outputs
- 2 siren outputs 24VDC. Independent and monitored open collector outputs
- Relay outputs
- 4 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
4 Salidas de Relé: 1 Salida de Alarma, 1 Salida de fallo y 2 salidas de relé configurables. Todas admiten 30VDC 3A máx. - End of line resistance
- Areas fully monitored by end-of-line resistance (4.7K)
- Auxiliary Output Voltage
- 24VDC. Protected by resettable electronic fuse 1.85A
24VDC. Protegido por fusible electrónico rearmable 1.85A - Protection Index
- IP30
- Material and colour
- ABS, colour: White
- Recommended cable
- Fire cable with a minimum section of 1.0mm (18AWG).
- Available languages
- English, French, Spanish, Turkish, Romanian and Russian.
DMTECH Control Repeater - 2 Siren output - 2 alarm and fault outputs and 2 configurable relay outputs - Allows up to 8 stations to be connected - Necessary module DMT-M9000-485 - LCD screen and advanced programming menu
