Dmtech DMT-FP9000E - Conventional detection and extinguishing station, 2…

Conventional detection and extinguishing station - 2 extinguishing lines and conventional detection 1 zone - 2 Siren output - Multiple configurable relay and open-collector outputs - Multiple inputs for pushbutton types - LCD screen and advanced programming menu
€217.10 €334.00 Save 35%
Tax included
Reference DMT-FP9000E
Brand Dmtech
Quantity
Available in 24/48h

Free shipping
Dmtech DMT-FP9000E - Central de detección y extinción convencional, 2…

Dmtech DMT-FP9000E - Conventional detection and extinguishing station, 2…

€217.10 €334.00 Save 35%

You might also like

  • DMTECH
  • Conventional detection and extinguishing station
  • 2 extinction lines
  • 1 conventional fire detection zone
  • Cross zone connection of detector 2 wires in the flood area
  • Multiple inputs for pushbutton types
  • 2 independent siren outputs
  • 2 auxiliary alarm and fault outputs
  • 2 configurable relay outputs
  • 4 configurable open collector outputs
  • Capacity for 2 12V batteries
  • 4 access levels
  • LCD display with menu for advanced programming

Features

  • Conventional detection and extinguishing station
  • 2 extinguishing lines and conventional detection 1 zone
  • 2 Siren output
  • Multiple configurable relay and open-collector outputs
  • Multiple inputs for pushbutton types
  • LCD screen and advanced programming menu

Specs

Primary power supplySwitching source 110-252V AC 50-60 Hz 55W max.
Backup power supply2 batteries 12VDC (up to 5 Ah). Ensures minimum 72 hours duration.
Number of extension lines2 cross-connected lines
Number of detection zones1 conventional zone, up to 30 detectors per zone.
Push-button inputsManual, Hold, Select mode, ON/OFF extinguishing and low pressure.
Siren outputs2 siren outputs 24VDC. Independent and monitored open collector outputs
Relay outputs4 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
Open collector outputs4 outputs
End of line resistanceAreas fully monitored by end-of-line resistance (4.7K)
Auxiliary Output Voltage24VDC. Protected by resettable electronic fuse 1A
Protection IndexIP30
Temperature-5ºC~+40ºC
Material and colourABS, colour: White
Dimensions310 x 240 x 80 mm
Weight1,3Kg
Recommended cableFire cable with a minimum section of 1.0mm (18AWG).

Package content

  • Extinguishing station
  • Battery cables
  • Fusible
  • End of line resistors
Dmtech

Data sheet

Weight
1,3Kg
Dimensions
310 x 240 x 80 mm
Temperature
-5ºC~+40ºC
Primary power supply
Fuente conmutada 110-252V AC 50-60 Hz 55W max.
Switching source 110-252V AC 50-60 Hz 55W max.
Backup power supply
2 batteries 12VDC (up to 5 Ah). Ensures minimum 72 hours duration.
2 batteries 12VDC (up to 7.2 Ah). Ensures minimum 72 hours duration.
Siren outputs
2 siren outputs 24VDC. Independent and monitored open collector outputs
Relay outputs
4 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
4 Salidas de Relé: 1 Salida de Alarma, 1 Salida de fallo y 2 salidas de relé configurables. Todas admiten 30VDC 3A máx.
End of line resistance
Areas fully monitored by end-of-line resistance (4.7K)
Auxiliary Output Voltage
24VDC. Protected by resettable electronic fuse 1A
24VDC. Protegido por fusible electrónico rearmable 1A
Protection Index
IP30
Material and colour
ABS, colour: White
Recommended cable
Fire cable with a minimum section of 1.0mm (18AWG).
Número de líneas de extición
2 líneas conn conexión cruzada
Número de zonas de detección
1 zona convencional, hasta 30 detectores por zona.
Entradas de pulsadores
Manual, Retención, Modo selección, ON/OFF extinción y baja presión.
Salidas de colector abierto
4 Salidas
Number of extension lines
2 cross-connected lines
2 lines with cross connection
Number of detection zones
1 conventional zone, up to 30 detectors per zone.
Push-button inputs
Manual, Hold, Select mode, ON/OFF extinguishing and low pressure.
Open collector outputs
4 outputs
