Dmtech DMT-FP9000-24-IT - Conventional central 24 areas with LCD screen, 2 Siren…

Conventional central 24 areas with LCD screen - 2 Siren output - 2 alarm and fault outputs and 10 configurable relay outputs - Repeater output - Up to 30 detectors per zone - End-of-line resistance auto detection
€730.00
Tax included
Reference DMT-FP9000-24-IT
Brand Dmtech
Quantity
In Stock

Free shipping
Hikvision DS-9664NI-ST -

Dmtech DMT-FP9000-24-IT - Conventional central 24 areas with LCD screen, 2 Siren…

€730.00

You might also like

  • DMTECH
  • Conventional fire alarm panel of 24 zones
  • Certificate EN54-2 and EN54-4
  • 2 independent siren outputs
  • 2 auxiliary alarm and fault outputs
  • 10 configurable relay outputs
  • Individual output for repeaters
  • Capacity for 2 12V batteries
  • 4 access levels ((3 user and 1 manufacturer)
  • LCD display with menu for advanced programming

Features

  • Conventional central 24 areas with LCD screen
  • 2 Siren output
  • 2 alarm and fault outputs and 10 configurable relay outputs
  • Repeater output
  • Up to 30 detectors per zone
  • End-of-line resistance auto detection

Specs

Primary power supplySwitching source 187-252V AC 50-60 Hz 65W max.
Backup power supply2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.
Available languagesSpanish, English, Portuguese, Italian, French, and German.
Number of zones24 zones, up to 30 detectors by area.
Siren outputs2 siren outputs 24VDC. Independent and monitored open collector outputs
Relay outputs12 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
End of line resistanceAreas fully monitored by end-of-line resistance (4.7K)
Auxiliary Output Voltage24VDC. Protected by resettable electronic fuse 1.85A
Protection IndexIP30
Temperature-5ºC~+45ºC
Material and colourABS, colour: White
Dimensions370 x 410 x 80 mm
Weight2.5Kg
Recommended cableFire cable with a minimum section of 1.0mm (18AWG).

Package content

  • Panels
  • Battery cables
  • Fusible
  • End of line resistors
Dmtech

Data sheet

Weight
2.5Kg
Dimensions
370 x 410 x 80 mm
Temperature
-5ºC~+45ºC
Primary power supply
Switching source 187-252V AC 50-60 Hz 65W max.
Backup power supply
2 batteries 12VDC (up to 18 Ah). Ensures minimum 72 hours duration.
Number of zones
24 zones, up to 30 detectors by area.
Siren outputs
2 siren outputs 24VDC. Independent and monitored open collector outputs
Relay outputs
12 Relay outputs: [VAR%] Alarm output, 1 Fault output and 1 configurable relay outputs. All support 30VDC 3A max.
End of line resistance
Areas fully monitored by end-of-line resistance (4.7K)
Auxiliary Output Voltage
24VDC. Protected by resettable electronic fuse 1.85A
Protection Index
IP30
Material and colour
ABS, colour: White
Recommended cable
Fire cable with a minimum section of 1.0mm (18AWG).
Available languages
Spanish, English, Portuguese, Italian, French, and German.
