Dahua DHI-ASC2204C-H Dahua access controller for 4 1-way doors

Dahua DHI-ASC2204C-H. Dahua access controller for 4 1-way doors. TCP / IP communication. RS-485 and Wiegand 26/34 reader interface. Up to 200,000 users / cards and 150,000 events. Unlocking by card, code, fingerprint and combinations. Antipassback and multiple blocking. Web server. Built-in RTC. Watchdog function Asc2204c-h.

Specifications

Access control controller for 4 doors and 1 direction

Supports 4 RS485 readers or 4 Wiegand readers

Multi-door interlocking

Capacity for 200,000 users / cards

150,000 event log

Supports unlocking by card, code, fingerprint and combinations

List of 128 periods and holidays

Antipassback, multiple lock, multiple card unlock

Allows blacklists

Supports 128 time groups, 128 period groups and 128 holiday period groups

4 RS-485 ports

4 Wiegand 26/34 ports

Inputs: 4 door status inputs, 4 door sensor inputs, 4 request-to-exit button inputs, and 8 alarm inputs

Outputs: 4 door lock outputs, 8 alarm outputs

1 10 / 100Mbps RJ45 port

Network functions: TCP / IP, UDP, HTTP, HTTPS, DDNS, Register, P2P, NTP, DST

Third-party platform support via Onvif (C), CGI, SDK

Remote access for up to 999 users

Watchdog function

Built-in RTC, DST compliant

Power supply: 85V ~ 264V AC, 50 / 60Hz

Operating temperature: -30 ° C ~ + 60 ° C

Relative humidity: ≤95%

SECC steel cab with lock

Dimensions: 270 (W) x 330 (H) x 90 mm

Weight: 2 kg
