Xtralis XTL-670021360 - XTRALIS ADPRO eFT 8IP 2TB HDD 4I/2O, Alarms 4I/2O,…

XTRALIS ADPRO eFT 8IP 2TB HDD 4I/2O - Alarms 4I/2O - Includes 8 IP video channels - Up to 16 IP channels reaching 8 IP channels with 8 video analysis channels - Hard Disk 2TB - LoiterTrace and IntrusionTrace licenses NOT included - I-LIDS Certification
Reference XTL-670021360
Brand Xtralis
Quantity

Free shipping
  • XTRALIS ADPRO eFT 8IP 2TB HDD 4I/2O
  • Includes 8 IP video channels
  • 2TB hard disk
  • 4 entradas y 2 salidas en el equipo
  • Up to 16 IP channels reaching 8 IP channels with 8 video analysis channels
  • LoiterTrace and IntrusionTrace licenses NOT included
  • Compatibility with main camera brands and ONVIF S-Profile
  • Video recording, video analysis and streaming (ready for complete remote monitoring)
  • Expandable: up to 128 inputs and 128 outputs with Ethernet PoE modules
  • Reliable data storage: support up to 2 x 10TB HDD
  • Programa Xchange Tool para instalacion y gestion de licencias
  • Mobile applications for monitoring, verification and remote control
  • Certificación i-LIDS
  • DGUV-UVV Kassen Certification
  • Compliance with BS 8418:2015

Features

  • XTRALIS ADPRO eFT 8IP 2TB HDD 4I/2O
  • Alarms 4I/2O - Includes 8 IP video channels
  • Up to 16 IP channels reaching 8 IP channels with 8 video analysis channels
  • Hard Disk 2TB
  • LoiterTrace and IntrusionTrace licenses NOT included
  • I-LIDS Certification

Specs

Operating system Operating system ADPRO® XO™ Security, based on Linux
Video output HDMI: 2 × HDMI interface; 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, (1920 × 1080)/60Hz, (1600 × 1200)/60Hz, (1280 × 1024)/60Hz, (1280 × 720)/60Hz, (1024 × 768)/60Hz
VGA: 1 × VGA interface; (1920 × 1080)/60Hz, (1280 × 1024)/60Hz, (1280 × 720)/60Hz, (1024 × 768)/60Hz
Video compression H.264/H.265 (H.265 compatible with Hikvision, Honeywell, ONVIF S/T profile and generic controller)
Video Resolution Up to 4K resolution; For optimal performance, when using 4K cameras on XO devices, the number of supported cameras and analysis channels (IntrusionTrace and/or LoiterTrace) are reduced in proportion to the resolution.
Images/second Full HD/1080p to 25/30 fps (PAL/NTSC)
Bandwidth (video) 16 x 5 Mbps
Bandwidth Management Configurable bitrate constant or variable / Bandwidth limiter
configurable
Audio input Audio input from compatible IP camera
Audio output Analog audio output ( 3,5 mm connector) and digital audio output from IP cameras. Support for zone-specific audio
Built-in inputs 4 inputs in the box
External inputs (Via XO USB I/O (monitored) + Network I/O unit with PoE
20 Entradas monitorizadas (con una conexión USB sencilla utilizando USB o E/S de alarma externa)
40 Monitored inputs (with dual USB connection using USB or external alarm I/O)
Up to 128 monitored inputs via Ethernet I/O units.
Relay outputs 2 outputs in the box
External relay outputs (Via XO USB I/O (monitored) + Network I/O unit with PoE
8 Monitored outputs (with a simple USB connection using USB or external alarm I/O)
16 Relay outputs (with dual USB connection using USB or external alarm I/O)
Up to 128 Relay outputs via Ethernet I/O units.
Web server XO client - integrated web client application (ActiveX)
SATA / Max HDD Storage. 2TB / 2 x 10TB
Ethernet network 2 x RJ45: Self-adapting Ethernet interfaces 10M/100M/1000M
PoE Support No
Recording Type Schedule/Detection/Event
IP camera integration Driver específico según la marca, genérico o driver ONVIF Perfil S/T (Depende de la cámara)
Management Web client interface (XO client), ADPRO VideoCentral Platinum, third party software (SDK available)
and iTrace app for iOS/Android
Power supply 12 VCC, 5A, 60W (power supply 230 VAC/12 VCC included)
Operating temperature from 0 to 40°C
Humidity from 10 to 93% non-condensing humidity
Warranty 2 years
Dimensions (length x width x height) 445mm × 290mm × 45mm
19" Compatible bracket No
Video Analysis Basic: Motion detection, Manipulation
Up to 8 xTrace Analytics channels: IntrusionTrace™, LoiterTrace™ (requires optional licenses)

Package content

  • Adpro eFT Unit
  • Power supply
  • Mouse
  • Hard disk extension cables

Data sheet

Operating temperature
from 0 to 40°C
Power supply
12 VCC, 5A, 60W (power supply 230 VAC/12 VCC included)
Video output
HDMI: 2 × HDMI interface, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, (1920 × 1080)/60Hz, (1600 × 1200)/60Hz, (1280 × 1024)/60Hz, (1280 × 720)/60Hz, (1024 × 768)/60Hz VGA: 1 × VGA interface, (1920 × 1080)/60Hz, (1280 × 1024)/60Hz, (1280 ×
Audio output
Analog audio output ( 3,5 mm connector) and digital audio output from IP cameras. Support for zone-specific audio
Humidity
from 10 to 93% non-condensing humidity
Operating system
Operating system ADPRO® XO™ Security, based on Linux
Management
Web client interface (XO client), ADPRO VideoCentral Platinum, third party software (SDK available) and iTrace app for iOS/Android
Relay outputs
2 outputs in the box
Video Resolution
Up to 4K resolution, For optimal performance, when using 4K cameras on XO devices, the number of supported cameras and analysis channels (IntrusionTrace and/or LoiterTrace) are reduced in proportion to the resolution.
Video analysis
Basic: Motion detection, Manipulation Up to 8 xTrace Analytics channels: IntrusionTrace™, LoiterTrace™ (requires optional licenses)
Video compression
H.264/H.265 (H.265 compatible with Hikvision, Honeywell, ONVIF S/T profile and generic controller)
Audio input
Audio input from compatible IP camera
Images/second
Full HD/1080p to 25/30 fps (PAL/NTSC)
Bandwidth Management
Configurable bitrate constant or variable / Bandwidth limiter configurable
Web server
XO Client - Integrated Web Client Application (ActiveX)
Recording Type
Schedule/Detection/Event
IP Camera Integration
Driver específico según la marca, genérico o driver ONVIF Perfil S/T (Depende de la cámara)
Warranty
2 years
Bandwidth (video)
16 x 5 Mbps
Built-in inputs
4 inputs in the box
External inputs
(Via XO USB I/O (monitored) + Network I/O unit with PoE 20 Entradas monitorizadas (con una conexión USB sencilla utilizando USB o E/S de alarma externa) 40 Monitored inputs (with dual USB connection using USB or external alarm I/O) Up to 128 monitore
External relay outputs
(Via XO USB I/O (monitored) + Network I/O unit with PoE 8 Monitored outputs (with a simple USB connection using USB or external alarm I/O) 16 Relay outputs (with dual USB connection using USB or external alarm I/O) Up to 128 Relay outputs via Ethernet
SATA / Max HDD Storage.
2TB / 2 x 10TB
Ethernet network
2 x RJ45: Self-adapting Ethernet interfaces 10M/100M/1000M
PoE Support
No
Dimensions (length x width x height)
445mm × 290mm × 45mm
19\" Compatible bracket
No
