X-Security XS-NVR3116-4K-1FACE - X-Security NVR for IP cameras, 16 CH IP video, Maximum…

X-Security NVR for IP cameras - 16 CH IP video - Maximum recording resolution 12 Mpx - 1 CH facial recognition - 2 CH human and vehicle recognition - Compression H.265+
Reference XS-NVR3116-4K-1FACE
Brand X-Security
Quantity

Free shipping
  • X-Security
  • NVR for IP cameras
  • 16 CH
  • 80 Mbps bandwidth supported
  • Maximum resolution 12 Megapixel
  • 1 CH facial recognition
  • 2 CH perimeter protection with human and vehicle classification
  • Compression H.265+/H.265/H.264+/H.264/MJPEG
  • VGA and HDMI 4K output
  • Mouse
  • Space for 1 HDD
  • WEB, CMS (DSS/PSS), Smartphone and NVR interface
  • ONVIF Compatible

Features

  • X-Security NVR for IP cameras
  • 16 CH IP video
  • Maximum recording resolution 12 Mpx
  • 1 CH facial recognition
  • 2 CH human and vehicle recognition
  • Compression H.265+

Specs

BrandX-SECURITY
Inputs for IP cameras16 channels
Video outputs1 HDMI 4K, 1 VGA
Bidirectional audio1 RCA input, 1 RCA output
Video compression formatH.265+/H.265/H.264+/H.264/MJPEG
Video analysisIVS: Line Crossing | Area Intrusion | Face Detection | Face Detection
Facial recognition1 live analogue face comparison channel
Intelligent motion detectionUp to 2 channels capable of classifying targets amongst humans and vehicles
Total bandwidth80 Mbps
Recording resolution12Mp, 8Mp (on 1 channel), 6Mp, 5Mp, 4Mp, 3Mp, 1080P (on 4 channel), 720P, D1...
Simultaneous multifunctionPentaplex: Live, Recording, Playback, Backup and Remote Access
AlarmsNo
Recording methodManual, programmed, motion detection
BackupUSB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA internal interface
Internal memory1 SATA HDD 3.5" of up to 8 TB (not included)
Communication2x USB 2.0 (Mouse and backup) /1 RJ45 10/100M (Ethernet)
Remote accessWeb browser (ActiveX), mobile phone application or PSS software
PowerDC 12 V / 1.5 A
Dimensions1U, 48 (H) x 260 (W) x 225 (D) mm / 0.8 Kg (without HDD)

Package content

  • X-SECURITY NVR
  • Mouse
  • Adapter AC/DC 12 V / 1.5 A
  • User instructions
  • CD with manual and software

Data sheet

Weight
300 g
Power
DC 12 V / 300 mA max
Resolution
4Mpx@25FPS (HDTVI, HDCVI, AHD) 5Mpx@20FPS(HDTVI, AHD)
Temp. operation
-10º C ~ +50º C
Degree of protection
Weatherproof IP66
Dimensions
70 (H) x 94 (Ø) mm
Material
Plastic
Range
5Mpx/4Mpx PRO
Video output
1 x BNC switchable HDTVI 2.0 / HDCVI / AHD / CVBS
Image sensor
1/3\" GC4653 CMOS Sensor
DSP
FH8538M
Minimum illumination
0 Lux / Matrix IR (30 m)
Basic functions
OSD menu, Day/Night with IR-CUT (ICR)
Configurable OSD functions
AE, 2DNR, AWB
Lens
2.7~13.5mm varifocal
