Uniview Pro UV-NVR302-16E-P16-B - NVR for IP cameras, Prime range, 16 CH video / Ultra…

NVR for IP cameras - Prime range - 16 CH video / Ultra Compression 265 - 16 PoE Channels - Maximum resolution 12Mpx - Space for 2 hard disks
Reference UV-NVR302-16E-P16-B
Brand Uniview Pro
Quantity

Free shipping
  • Uniview
  • NVR for IP cameras
  • Prime range
  • 16 CH
  • 160 Mbps bandwidth supported
  • Maximum resolution 12 Megapixel
  • Compression Ultra265/H.265/H.264
  • Intelligent functions
  • Smart Intrusion Prevention on 16 channels
  • Fisheye: Dewarping and Heat Mapping
  • Alarms
  • VGA and HDMI 4K output
  • Mouse
  • Space for 2 HDD
  • 16 PoE ports IEEE802.3af/at
  • WEB, CMS, Smartphone and NVR interface
  • ONVIF Compatible

Features

  • NVR for IP cameras
  • Prime range
  • 16 CH video / Ultra Compression 265
  • 16 PoE Channels
  • Maximum resolution 12Mpx
  • Space for 2 hard disks

Specs



Brand Uniview
Range Prime
Inputs for IP cameras LAN port up to 16 channels
Power over Ethernet 16 port PoE Switch IEEE802.3af/at (max. 240 W) | Hasta 250m en modo PoE extendido
IP compatible cameras UNIVIEW, ONVIF
Bidirectional audio 1 input / 1 RCA output
Video outputs 1 HDMI 4K, 1 VGA
Video compression format Ultra H.265 / H.265 / H.264
Display resolution 3840x2160, 1920x1080, 1600x1200 1280x1024, 1280x720, 1024x768
Total bandwidth 160 Mbps downstream / 320 Mbps upstream
Main Stream recording 12Mpx / 8Mpx / 6Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 720p / D1 / 2CIF / CIF
Alarms 4 inputs / 1 relay
Recording method Manual, programmed, motion detection
Intelligent functions People Counting, Facial Recognition, Vehicle Recognition, Face Detection, Intrusion Detection, Line Crossing, Scene Change, Blur Detection, Auto Tracking, Removed Object, Abandoned Object
Smart Intrusion Prevention
 Available at 16 channels
Fisheye Dewarping, Heat Map
POS (Point of Sale)
 Yes
External Backup USB / HDD USB memory
Internal memory 2 SATA HDD 3.5" of up to 10 TB (not included)
Communication 2 x USB 2.0 / 1 x RJ45 (Ethernet)
Remote access Web browser, Safire Control Center Smartphone App and PC Software
Power AC 100~240 V, 50/60 Hz
Dimensions / Weight 46 (H) x 380 (W) x 315 (D) mm / 2.48 Kg

Package content

  • Uniview NVR
  • Mouse
  • Power supply cable
