Multifibre 24 fibers multifiber cable LSFH interior Ø 250μm Televes
search
  • Multifibre 24 fibers multifiber cable LSFH interior Ø 250μm Televes

Multifibre 24 fibers multifiber cable LSFH interior Ø 250μm Televes

24 fiber cable and LSFH cover for indoor installation. They are divided into 3 micromodules of 8 fibers, each with LSFH cover and a different color. This improves your organization and facilitates identification. Fiber coating Ø 250μm.
It is supplied in coils to measure (to the meter). Televes 231612

€4.59
Tax included
Reference televes-231612
Brand Televes
Quantity
Available in 24/48h

Free shipping
Multifibre 24 fibers multifiber cable LSFH interior Ø 250μm Televes

Multifibre 24 fibers multifiber cable LSFH interior Ø 250μm Televes

€4.59

Check availability and shipping time.

24-fibre cable with LSFH sheath for indoor installation. Divided in 3 micro-modules of 8 fibres each, each with its own LSFH sheath and different colour. This provides a better organization and makes identification easier.
Provided in custom reels (by meters).

Highlights

  • Low attenuation
  • Water protection
  • Organized in fibre micro-modules
  • The micro-module includes aramid fibres (kevlar) to reinforce its structure

Features

  • 9/125, ITU-T G.657A2 fibre type
  • Coating diameter adapted to the fibre: 250 μm
  • Equipped with a core guiding wire for resistance
  • LSFH sheath, orange colour

Specifications

Cable type   Vertical distribution cable 24C
Fiber type   9/125 (G657A2)
Attenuation dB/Km ≤0.4 for 1310nm; ≤0.3 for 1550nm
Tight buffer material   LSFH (Low Smoke Free Halogen) & flame retardant
Tight buffer diameter mm 0.25 ±0.05
Jacket material   LSFH (Low Smoke Free Halogen) & flame retardant
Jacket color   PANTONE 136 C
Cable diameter mm 8 ±0.2
Min. bending radius.   10 x Cable Diameter
Short tension N 1200
Short crush N/100mm 1000
Operation temperature ºC -20 ... 70
