SELECT * FROM ps_od_oosbutton_manufacturer WHERE id_manufacturer = 46SELECT * FROM ps_od_oosbutton JOIN ps_od_oosbutton_lang USING (id_product) WHERE id_product = 2028 AND id_lang = 1 Koovik 4STREAMPro6-HDMI - Professional IP Streamer with 4 HDMI inputs
Koovik 8STREAMPro6-HDMI, Streamer IP profesional de 8 entradas HDMI
search
  • Koovik 8STREAMPro6-HDMI, Streamer IP profesional de 8 entradas HDMI
  • Koovik 8STREAMPro6-HDMI, Streamer IP profesional de 8 entradas HDMI
  • Koovik 8STREAMPro6-HDMI, Streamer IP profesional de 8 entradas HDMI
  • Koovik 4STREAMPro6-HDMI, Streamer IP profesional de 4 entradas HDMI

Koovik 4STREAMPro6-HDMI - Professional IP Streamer with 4 HDMI inputs

It has 4 HDMI inputs, an ASI input and an IP input.

The integrated multiplexer allows to build a new TS with the available services of the HDMI inputs, the ASI input and the IP input.

Two ASI outputs and one IP streaming output (1 MPTS and 4 SPTS) simultaneously. Maximum: 100Mbs.

€3,395.01
Tax included
Reference koovik-4STREAMPro6-HDMI
Brand Koovik
Quantity
Available in 24/48h

Free shipping
Koovik 8STREAMPro6-HDMI, Streamer IP profesional de 8 entradas HDMI

Koovik 4STREAMPro6-HDMI - Professional IP Streamer with 4 HDMI inputs

€3,395.01

Koovik 4STREAMPro6-HDMI, Professional IP Streamer with 4 HDMI inputs, an ASI input and an IP input.

The integrated multiplexer allows to build a new TS with the available services of the HDMI inputs, the ASI input and the IP input.

Two ASI outputs and one IP streaming output (1 MPTS and 4 SPTS) simultaneously. Maximum: 100Mbs.

It has two separate IP ports. One for streaming and one for control. Rack format of 19 "1U.

It is applied in

  • Contribution and transport of multimedia signals
  • Distribution of audiovisual content over IP networks (including WiMAX and WiMAX) in links
  • IPTV headers for hotels
  • Campus
  • Monitoring
  • Broadcast professional
    Etc...

Built-in keyboard and LCD screen.

The 4STREAMPro6 has a built-in keyboard and LCD screen for quick configuration without the need for additional tools.

Configuration using WEB manager

When a more detailed configuration is required, save or reuse a configuration, the 4STREAMPro6 can be adjusted using its embedded web server. Simply connect your laptop to the NMS Ethernet connector (either directly or to your local network). Enter the IP address in a standard browser, and you will see the configuration menu protected by username and password. No software installation is required.

Using the NMS, the installer has full access to the configuration of all the parameters.

You can also save the configuration parameters for later reuse on this or another computer.

Specifications

ENCODER
VÍDEO CODEC MPEG4 AVC H.264. Perfil High y Main.
RESOLUCIÓN 1080p 50/60fps, 1080i 50/60fps, 720p 50/60fps, 576i 50fps, 480i 60fps
ESCALADO Equal to the input resolution, or reduce to 1080i 50 / 60fps, 1440x1080i 50 / 60fps, 720p 50 / 60fps, 576i 50fps.
BIT-RATE 0.8 Mbps at 19 Mbps. CBR or VBR. Independent adjustment for each video input.
GOP STRUCTURE IBBP
PRE-PROCESSING De-interlacing, noise reduction, improve sharpness.
AUDIO CODEC MPEG-1 LAYER 2, AC3 PASSTHROUGH. (HE-AAC V2, and LC-AAC with the AAC option)
BIT RATE 64Kbps to 384Kbps
SAMPLE RATE 48KHz (Resolution: 24 Bits)
ADJUSTMENT OF LEVEL 0 - 400
REMUX ASI remultiplexed input with 4 x HDMI TS to ASI output

INPUTS
HDMI 4 x HDMI inputs
ASI 1 × BNC 75 Ω female. 270 Mbit / s. 800 mV (Vpp). Standard EN 50083-9.
OUTPUTS
IP SPTS 4 SPTS over UDP or RTP / RTSP. Unicast or Multicast.
IP MPTS 1 Output MPTS 4 x HDMI TS over UDP or RTP / RTSP remultiplexed with ASI. Unicast or Multicast.
ASI 1 x ASI (2 identical ASI outputs). ASI remultiplexed input with 4 x HDMI TS. BNC 75 Ω female.
ETHERNET Interfaz Ethernet 1GigaE 1000Base-T.
GENERAL
CONFIGURATION Local: Front panel LCD display and keyboard. Network Management Setup - NMS: Embedded web server (English).
FEEDING Universal switched power supply (100 to 240VAC, 50 / 60Hz), Consumption: 25VA
DIMENSIONS Equipment: 483x420x44mm (WxHxT) including connectors. Packing: 600x600x140mm (WxHxT)
WEIGHT Net: 4.0 Kgs Gross: 4.5 Kgs
TEMPERATURE Operation: 0 to 45 ° C. Up to 90% humidity Storage: -20 to 80 ° C up to 90% humidity.
INCLUDED 1 x network cable, 1 x ground cable, 4 x HDMI to HDMI cable, 2 x BNC male to BNC male.
