Vonets VM300-H 300 Mbps WiFi Module
Professional wifi module with multiple functionalities and up to 5 ports with which you can control it. It supports 3G and 4G via USB, router mode, signal repeater mode to expand the coverage of WiFi signals, intelligent bridge mode, as a receiver or as an access point, and has two GPIO ports that can be controlled through a Socket .
€48.00
Tax included
Reference
vonets-VM300-H
Brand
Vonets
Vonets VM300-H 300 Mbps WiFi Module
€48.00
You might also like
VONETS 2.4G 300Mbps Wifi Module Wireless Repeater Wifi Bridge Ethernet Adapter Router WiFi AP Wifi Signal Booster Hotspot Extender Amplifier Wireless to Wired VM300-H
Features
- Main chip working frequency: 580MHz
- 32Mb SDRAM, expandable to 64Mb; 8Mb SPI Flash, expandable to 16Mb (Byte)
- WiFi working frequency band: 2.4GHz, 2T2R dual antenna, 300Mbps transmission rate
- Support 1--14 WiFi channels
- Rated power < 3W
- Module RF output power 13.5dbm--14.5dbm
- Supports temperature compensated frequency stabilization technology (TAFC), and the WiFi signal is stable.
- Support for 802.11b/g/n mode
- Working environment temperature: -25 °C - 50 °C
Functional characteristics
- Two software controllable working modes: routing mode, bridge + relay mode
- Support intelligent transparent bridge mode, support AP Client and AP Station
- Independent hardware data processing, no consumption of host system resources, no need to install any driver
- Stupid configuration in bridge mode, convenient for secondary development and implantation into other host systems
- Built-in WEB configuration service, can configure module working parameters through webpage
- Built-in SOCKET monitoring service, used to control two GPIO (1.5A) output, 9 kinds of GPIO control status, convenient for secondary development and function expansion
- Support VDNS technology, in the bridge mode, you can use the domain name login configuration page to solve the configuration and secondary development problems.
- Two external antenna RF carriers
- Online software upgrade.
Datasheet in attachments
Specifications
| Hardware | |
| Main chip frequency | 580 MHz |
| Memory | 32Mb SDRAM, expandable to 64Mbytes. |
| 4Mb SPI flash, expandable to 8Mbytes. | |
| Interfaces | MINI PCIE, 6PIN Female, 6PIN Pin, 8PIN Pin, RJ45 Female |
| WiFi signal frequency | 2.4 GHz |
| Number of antennas | two |
| RF output power | 14.5 dBm - 16 dBm |
| WiFi channels | 1-14 |
| WAN ports | 1 |
| LAN ports | 1 |
| Supports 3G / 4G | Yes (with USB device) |
| Features | Firewall, QoS, VPN |
| Protocols | Wi-Fi 802.11 B / G / N |
| Transmission speed max. | 300 Mbps |
| Operating modes | Router, Bridge (as receiver or access point), Repeated |
| Others | |
| Voltage | 3.3 V - 3.4 V DC, 4.5 V - 15 V DC |
| Power | <2W |
| Size | 51 × 30 mm |
| Weight | 86g |
| Ambient operating temperature | -25 ° C - 55 ° C |
Professional wifi module with multiple functionalities and up to 5 ports with which you can control it. It supports 3G and 4G via USB, router mode, signal repeater mode to expand the coverage of WiFi signals, intelligent bridge mode, as a receiver or as an access point, and has two GPIO ports that can be controlled through a Socket .
