Housing Power Supply 1i/2os F: 5...862MHz 24V-130mA Blister Televes

24V (130mA) home power supply, which sends power through the input coaxial cable, allowing the TV signal to pass through. It is sandwiched in the installation to power mast amplifiers or a BOSS system. In addition, it incorporates a distributor to generate two outputs. It also serves to feed MRD from antennas. Blister

€59.15 €91.00 Save 35%
Tax included
Reference televes-550402
Brand Televes
Quantity
Available in 24/48h

Free shipping
Safire SF-T943-PIRS-2E4N1 - Safire 4n1 Turret Camera, ECO Range, 2 MP High…

Housing Power Supply 1i/2os F: 5...862MHz 24V-130mA Blister Televes

€59.15 €91.00 Save 35%

You might also like

Blister

Power supply "F"

24V - 130mA, 2 outputs

24V (130mA) home power supply, which sends power through the input coaxial cable, allowing the TV signal to pass through. It is sandwiched in the installation to power mast amplifiers or a BOSS system. In addition, it incorporates a distributor to generate two outputs.

It also serves to feed MRD from antennas.

Stands out for

  • High performance switching power supply: consumption savings of up to 40%
  • Discreet, restrained design
  • "F" connectors
  • Fully automated manufacturing subjected to rigorous quality controls

Main features

  • Screwable on wall
  • The step losses vary depending on whether 1 or the 2 outputs are used

Specifications

Frequency range MHz 5 - 862
Step losses 1 out dB Main: 1.5 typ. / Aux: ---
2 out Main: 4 typ. / Aux: 4 typ.
Output voltage V --- 24
Current
max. exit		 mA 130
Current
min. exit		 mA 30
Feeding 207-253V ~ 50 / 60Hz
Consumption max. mA ~ 35
Protection index IP twenty
Operating temperature ºC -10 ... +45
Plug type EU

Application example

2021-10-15

Data sheet

Weight
390 g
Power
DC 12 V / 550 mA max / 6.6 W
Resolution
1080P at 25 FPS
Temp. operation
-40º C ~ 60º C
Degree of protection
Weatherproof IP67
Dimensions
93.7 (D) x 109.8 (Ø) mm
Material
Metal and Plastic
Range
4N1 1080p ECO
Video output
1 x BNC HDTVI, HDCVI, AHD and Analog
Image sensor
2 MP High Performance CMOS
Minimum illumination
Night Color 0.01 Lux
Configurable OSD functions
DWDR, 2D-NR, AWB, AGC, BLC and HLC
Lens
2.8 mm (D:124º / H:106)
PIR detection
Range: 11m | Angle (110º) | HDTVI coaxial recorder alarm
Speaker
Deterrent siren
White LED light
Range 20 m configurable as flash or courtesy light
Deterrent light
Red and blue LEDs with strobe flash effect
Alarm output
1 Relay output (dry contact)
