Triax ALF 202 Power supply 24 Vdc/200mA
Regulated power supply. 24 VDC - 200 mA, 2 outputs. Connectivity F. Presence of secondary voltage LED. Loss of passage: 4 dB. Power supply of the MFA range. Wall or DIN rail mounting.
€24.19
Tax included
Reference
triax-369116
Brand
Triax
Triax ALF 202 Power supply 24 Vdc/200mA
€24.19
Regulated power supply.
Features
- 24 VDC - 200 mA, 2 outputs.
- Connectivity F.
- Presence of secondary voltage LED.
- Loss of passage: 4 dB.
- Power supply of the MFA range.
- Wall or DIN rail mounting.
Specifications
| INFORMATION OF ORDER | |
|---|---|
| EAN Code | 3700113430158 |
| FREQUENCY BAND | |
| Bandwidth | 47-862 MHz |
| ATTENUATION | |
| Passage losses | < 4 dB |
| ELECTRICAL CHARACTERISTICS | |
| Impedance | 75 Ω |
| OPERATING | |
| AC power supply voltage | 230 VAC |
| Output voltage | 24 VDC |
| PSUmaxDCcurrent | 200 mA |
| CONNECTORS | |
| Type of connector | F-female |
| MECHANIC | |
| Depth | 40 mm |
| Width | 116 mm |
| Height | 80 mm |
| Quantity per package | 1 |
| Net weight | 0.230 kg |
| Packing weight | 0.050 Kg |
| Gross weight | 0.280 Kg |
Regulated power supply. 24 VDC - 200 mA, 2 outputs. Connectivity F. Presence of secondary voltage LED. Loss of passage: 4 dB. Power supply of the MFA range. Wall or DIN rail mounting.
