Hybrid satellite decoder. The integrated IP module allows the reception of high definition television and the use of the Internet. The decoder is equipped with a new standard FULL HD dual satellite head and a universal head for receiving DVB-T / T2 terrestrial channels.

The perfect complement to this receiver is the extremely clear screen. The unique design and aluminum housing make the Ariva ATV TT ideal for modern interiors. The decoder allows the reception of paid programs and prepaid television. All you need is an appropriate subscription card.

Features

• Full HD satellite receiver Twin tuner PVR / H.265 MPEG4-HD / SD DVB-S2
• Simultaneous recording - while watching one program recording another (in Full HD quality)
• DTT television, satellite
• Reception of programs in high definition UHD / 4K HDR
• Support for MPEG-2, MPEG-4, AVC / H.264, HEVC / H.265 standards
• Support of all SD, HD, FullHD, 4K video formats
• Android for TV
• DTS, AC3, DTS-MA, DTS-HR, PCM / 2.0 decoding, support for passthrough modes for all audio formats
• Support for video files with very high bit rates, sufficient for future UHD formats
• Card reader for payment programs
• Compatible with DVB-S / S2 H.265 / HEVC

Connect the mouse and keyboard. Transmit audio. Make the most of your Bluetooth!
HEVC H.265 video decoding gives you new perspectives, enjoy the full spectrum of new 4K image experiences!

The heart of the receiver is the Hisilicon Hi3798C200 chipset, which is equipped with peripherals such as an Ethernet communication interface, 3 USB ports (2 x 2.0 and 1 x 3.0), HDMI 2.0a TX video output with HDCP2.2 mechanism support, S / PDIF port for audio signal transmission, 10/100 / 1000Mbit LAN, DVB-S2 digital television system standard, smart card slot port and DC 12V / 3A power outlet.

The system is adapted to work with Android TV and Linux systems. The board itself has 16 GB of eMMC flash memory and 2 GB of DDR3 RAM. The exclusive ARM Mali T720 graphics card and the high-performance ARM Cortex A53 processor powered by 64-bit ARMv8 cores will provide console performance and lower power consumption.

RECORD AND SEE!

Are you worried about missing your favorite series? Simply plug the USB device or a hard drive into the USB port and from now on you can record any program or entire seasons of TV series arbitrarily set the time!

4K, UHD, HDR

Incredible image quality and 4 times more details than in Full HD! From now on you can enjoy crisp images like never before.

VERSATILE TV RECEPTION.

Thanks to the double head, you can watch satellite or terrestrial TV DVB-T2. In addition, each of the TV signals is doubled. For example, you can record one program while watching another live.

CARD READER FOR TV PAYMENT.

Thanks to the Pay-TV (CA) card reader, you can enjoy encrypted TV shows. The standard also includes an Ethernet / WiFi interface

MODERN VIDEO RECORDER.

From now on, you won't miss a second of your favorite show, record movies and TV shows comfortably on an external hard drive or USB storage device. You can also stop live television using the unique Timeshift function to continue later.

Inputs / Outputs

1. WiFi antenna
2. DVB-S2
3. DVB-S2
4. AV
5. S / PDIF
6. HDMI
7. USB 3.0
8. 2 x USB 2.0
9. Ethernet
10. DC INPU

Specifications

• Main chipset

  • HiSilicon HI3798C V200 up to 1.6GHz, Quad-Core
  • CPU Architecture: ARM Cortex A53
  • GPU: ARM Mali T720 (OpenGL ES 3.1, 3.0, 2.0, 1.1 and OpenCL 1.1)
  • SDRAM: 2GB DDR3 SDRAM
  • Storage: 16 GB EMMC (system and recovery partitions included)
• DVB-S2 tuner

  • Input connector: type F Female
  • Frequency range: 950MHz to 2150MHz
  • Signal level: -25 to -70dBm
  • Power and polarization LNB: Vertical: + 13.5V ± 0.5V Max 250mA; Horizontal: + 18.5V ± 0.5V Max 250mA
  • 22KHz Tone: Frequency: 22KHz ± 4KHz, 0.6Vp-p ± 0.2Vp-p
  • Diseqc Control: Version 1.0, 1.2, Compatible with USALS
  • Demodulation: QPSK and 8PSK
  • Input symbol rate: DVB-S: 1 ~ 55Mbps / DVB-S2: 1 ~ 45Mbps

• Technical data

  • Transport flow: ITU-T H.265 / HEVC and H.264, ISO / IEC 13818-2 MPEG-2, AVS and AVS +, VC1, VP6, VP8, VP9
  • Profile level: ITU-T H.265 Main 10 Profile @ L5.1 high level, MPEG-2 MP @ HL
  • Input speed: Max. 160Mbit / s (H.265)
  • Video format: 4: 3, 16: 9, Letter Box, Pan & Scan
  • Video resolution: 10bit, Up to 4096x2160px @ 60fps, Support HDR 10
  • Audio decoding: MPEG I&II, MP3, Dolby True HD and Digital Plus, AAC-LC, HE-AAC V1 / V2
  • Audio mode: Stereo / Mono / Left / Right / Swap
  • Bluetooth: 4.0 + EDR
  • HDMI: HDMI 2.0a TX with HDCP 2.2, 4K 10bit UHD @ 60Hz up to 4096x2160px, 1080p / i, 720p / i, 576p / i, 480p / i
  • Ethernet: RJ45 10/100 / 1000Mb Ethernet interface
  • Wi-Fi: DualBand 2.4 / 5GHz 802.11a / b / g / n / ac
  • USB: 1x USB 3.0 port, 2x USB 2.0 port
  • Ports: AV, HDMI 2.0a HDCP 2.2, HDCP1.4, USB 2.0, USB 3.0, S / PDIF, LAN 10/100 / 1000Mbit, DC 12V / 3A, DVB-S2, smart card slot
  • Software: Android TV 8 and Linux Debian or Enigma 2 dual operating system
  • Video support: HDTV, MPEG-2 SDTV, MPEG-4, H.264, HEVC / H.265, AVS, DivX 2K / 4K Decoding
  • Support video formats: MKV, MP4, WMV, MPG, MPEG, DAT, AVI, MOV, ISO, others through applications
  • Video container support: MKV (h.264, HEVC / h.265), WMV, MP4, RM, RMVB, TS, AVI, VOB, MOV (h.264, HEVC / h.265), ASF, 3GP, others through applications
  • Passtrough audio support: AC3 / Dolby Digital 5.1, E-AC / Dolby Digital +5.1, Dolby Digital +7.1, TrueHD 5.1, TrueHD 7.1, Dolby Atmos 7.1, DTS HD Master, High
  • Resolution DTS, DTS X
  • Audio container support: MP3, WMA, WMA, AAC, OGG, OGA, FLAC, ALAC, others through applications
  • Input voltage: AC 90 ~ 250V, 50 / 60HZ, DC 12V / 3A
  • Power consumption: depends on the use of the components (HDD, others)
  • Power consumption in standby mode: = <0.5W
  • Storage temperature: -10 ~ 70 ° C
  • Operating temperature: 0 ~ 45 ° C
  • Humidity: <95%
  • Net weight: 1.1kg
