Data sheet

Weight

740 g

Power

DC 12V / 0.48A, max. 5.8W, PoE IEEE802.3af max. 6.8W

Temp. operation

-30º C ~ +60º C

Degree of protection

IP66

Dimensions

126.3 mm (H) x 138.3 (Ø) mm
135 mm (h) x 135 mm (w) x 63 (d) mm

Transfer Rate

32 Kbps ~ 16 Mbps

Material

Metallic

Audio

Built-in microphone

Colour

White

Image sensor

1/1.8\" Progressive Scan CMOS

Minimum illumination

0.003 Lux / F1.6 Ultra Low Light Color

Lens

2.8 mm (H:102º, V: 55º, D:120º)

Maximum resolution

8 Megapixel (3840x2160)

Infrared lighting

0 Lux / IR LEDs (30 m)

Image improvements

WDR (120dB), BLC, 3D-DNR, HLC, MD, ROI

Day / Night

Removable mechanical ICR filter

Use

Valid for interior/exterior

Composition

Plastic

Base dimensions

128 (Ø) mm (3 screws) / 46 x 83.5 mm (4 screws)

Alarms

No

Internal memory

MicroSD card, Max 256 GB

Remote access

NVR, Web Browser, App Smartphone and PC Software Safire Control Center

Main Stream rate

3840 × 2160, 3072 × 1728 (1 ~ 20 FPS) 2688 × 1520, 1920 × 1080, 1280 × 720 (1 ~ 25 FPS)

Extra Stream rate

640x480, 640x360, 320x240 (1 ~ 25 FPS)

Compression

H.265+ / H265 / H.264+ / H264

Network interface

Ethernet 10/100 BaseT

Interoperability

ONVIF

People counting

YES, 95% Precision (Compatible with the firmware V5.5.131 build version 200702) TrueSense, Face capture and People Counting cannot be active at the same time

Inclination

11 degrees

Advanced features

Line crossing detection | intrusion | entry | exit region

Truesense 2

Motion Detection, Line Crossing, Entry / Exit area TrueSense, Face capture and People Counting cannot be active at the same time

Face Capture

YES (Compatible with Safire\'s Face Recognition recorders) TrueSense, Face capture and People Counting cannot be active at the same time

Mask Detection

YES (Compatible with the firmware V5.5.131 build version 200702) People Counting and Mask Detection use different firmware files

Permitted diameters

Up to 114 mm
