[Refurbished] Edision Picco T2 DVB-T2 Terrestrial Receiver

EDISION PICCO T2 is a H.264 high definition DVB-T2 terrestrial receiver, MPEG4, with improved menu navigation and user experience. It has 4-digit LED display, buttons on the front panel for on/off and channel -/+ more universal 2-in-1 remote control for the receiver and the TV.

€42.47 €65.34 Save 35%
Tax included
Reference edision-01-07-0021
Brand Edision
Quantity
Available in 4/5 days

Free shipping
INJ-POE-30W-UPS - PoE injector, Input/Output RJ45 10/100/1000 Mbps,…

[Refurbished] Edision Picco T2 DVB-T2 Terrestrial Receiver

€42.47 €65.34 Save 35%

EDISION PICCO T2 is an H.264, MPEG4, Full High Definition DVB-T2 receiver, with improved menu surfing and user experience. It has 4-Digit LED Display, front panel buttons for Power ON/OFF and Channel -/+ plus Universal Remote Control 2in1 for the receiver and the TV, with four LG/SAMSUNG(*) default settings which can be also programmable. It also features PVR function and external IR port in order to connect a Jack-to-IR cable and make the receiver "invisible"! Your best TV friend, with more features from EDISION!

Features

  • Type: Digital Terrestrial Receiver for DVB-T2 with Dolby Support
  • Full HD H.264 decoding support
  • Resolution: 480p, 576p, 720p/50Hz, 720p/60Hz, 1080i/50Hz, 1080i/60Hz, 1080p/50Hz, 1080p/60Hz TV Standard
  • 1 x HDMI output for High definition video/audio
  • 1 x Scart
  • 1 x IR in (jack)
  • 1 x S/PDIF output
  • 1 x USB
  • 1 x LED Display
  • 1 x ANT IN
  • 6000 TV/Radio channels memory
  • PAL/NTSC auto-switch
  • Multilingual OnScreenDisplay
  • EDIVISION electronic program guide
  • Supports Picture In Grafik (PIG)
  • Channel Edit and Favourite Lists
  • Auto and Manual channel search
  • Auto-timer Οn/Off
  • PVR via USB
  • Τime Shift function
  • Subtitle support
  • Teletext support
  • Last channel auto save
  • Software upgrade & backup/channel list, via USB
  • Supports FAT 16/32, NTFS
  • Parental control
  • 100 ~ 240V Voltage,50Hz/60Hz
  • Media player MP3/JPEG/BMP/AVI/DivX/VOB/MKV

Front Panel

  • Display: LED
  • Display Buttons: Power, Channel -/+
  • 1 x USB 2.0 slot

Side Panels

  • 1 x Jack to IR

Back Panel

  • Input ANT-IN: 1x IEC-type
  • Connection TV: 1x HDMI, 1x Scart
  • Video output: 1x HDMI, 1x Analog Video
  • Audio output: optical (S/PDIF)
  • 1 x DC for Power Supply

Package Content

  • IR remote control 2in1
  • 5v external power supply unit
  • 2 x "ΑΑΑ" batteries
  • Mini Manual GR/EN/DE

General

  • Dimensions: (W x H x D): 125x120x35 (mm)
  • Weight: 0.5 kg
  • Color: black
  • Warranty: 2 years

*= LG & SAMSUNG are brand names that belong solely to LG Electronics Inc. and Samsung Electronics Co., Ltd respectively. Any brand name reference in this text is only for informational purposes towards the consumer that is interested in the product. There is a minor percentage that some SAMSUNG & LG TV models or some of their functions are not fully supported or not supported at all. If this situation occurs, please contact us.

Data sheet

Weight
338 g
Power
AC 90 V - 240 V
DC 12 V / 324 mA / 3.7 W max
Resolution
5Mpx to 20 fps,4Mpx to ≤30 fps, 1080P to 30 fps
Temp. operation
-40º C ~ +60º C
Degree of protection
Weatherproof IP67
Dimensions
158 (D) x 35 (H) x 142 (W) mm
216.6 (D) x 78.9 (W) x 75.4 (H) mm
Operating temperature
-30º C - 70º C
Power supply
30 W (Max. 46~52 VDC)
Material
Front cover: Metal, Main Body: Plastic
Range
PRO
Video output
1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS
Audio
Built-in microphone (Audio via coaxial cable)
Image sensor
5 MP CMOS
Minimum illumination
0.01 Lux @(F1.2, AGC ON)
Basic functions
OSD menu (remote)
Configurable OSD functions
3D-DNR, AWB, ATW, BLC, AGC, Mirror, Smart IR
Lens
6 mm
Maximum resolution
5 Mpx (2560x1944)
Infrared lighting
0 Lux / SMART IR (40 m)
Day / Night
Auto / Colour / BW (Black and White)
PoE features
According to IEEE 802.3af/at
Maximum range
100 meters
Interface
Input / Output RJ45 of 10/100/1000Mbps
Power supply outputs
1x jack DC 12 V max 3 A - 1x DC 24/48 V selectable
UPS function
Battery support 12V 30H (not included)
Base diameter
55 (Ø) mm / 3 screws
Lens Adjustment
3 Axis
Video output switching
Via Switch
Passive PoE features
24 V to 24 W
