[Refurbished] Ferguson Ariva 104 Full HD satellite receiver
Reception of programs in high definition Full HD. Support for MPEG-2, MPEG-4, AVC/H.264, HEVC/H.265 standards. Support of all SD, HD, FullHD video formats. Teletext support and subtitles. Network service (movies, radio, etc.) MPEG-1 layer I/II decoding, PCM downmix, IEC958 S/PDIF, Dolby 5.1 channel, Dolby downmix 2 channel, Dolby Prologic 2.
€50.34
€77.44
Save 35%
Tax included
Reference
ferguson-ariva-104
Brand
Ferguson
Available in September
Ariva 104 is a new Full HD satellite receiver with a built-in card reader for pay-TV. This device has an integrated PVR Ready function, which together with a USB 2.0 input allows you to record programs on an external hard drive.
The decoder housing is made of the highest quality materials. This decoder has a 4-digit readable LED display. The small and elegant shape of the housing and the timeless front panel of the decoder make them ideal for any interior!
The Ariva 104 satellite tuner thanks to the use of two USB ports offers the possibility of connecting an external storage medium. Playing music (mp3, ogg, flac), movies (mkv, avi, xvid) and viewing photos (jpeg, bmp) are just some examples of the use of this versatile device.
RECORD AND SEE!
Are you worried about missing your favorite series? All you have to do is connect an external memory to the USB socket and from now on you can record any program or complete seasons of your favorite series at any time you set!
WEB SITES AT YOUR REACH
Connect the Ferguson W03 WiFi adapter (not included) to enjoy the full range of movies and services for every mood!
Features
- Reception of programs in high definition Full HD
- Support for MPEG-2, MPEG-4, AVC / H.264, HEVC / H.265 standards
- Support of all SD, HD, FullHD video formats
- Teletext and subtitle support
- Network service (movies, radio, etc.)
- MPEG-1 layer I / II decoding, PCM downmix, IEC958 S / PDIF, Dolby 5.1 channel, Dolby downmix 2 channel, Dolby Prologic 2
- Support for DiSEqC 1.2, 13 / 18V, 0 / 22K, LNB
- Card reader for payment programs
Inputs / Outputs
- LNB IN
- 2 x USB 2.0
- Ethernet
- DV output
- S / PDIF
- DC input
- SCAR
Specifications
- Main chipset
- CPU frequency: 554MHz
- Flash Memory: 1PC 4Mbyte / 8Mbyte SPI FLASH
- SDRAM memory: 1PC 128Mbyte DDR3
- DVB-S / S2 tuner
- Tuner Type: M3031 Integrated
- Frequency range: 950 ~ 2150MHz
- Input impedance: 75Ω
- Power and polarization LNB: vertical 13VDC; Horizontal tone from 18 VDC to 400 mA (max.) 22 kHz ± 0.4 kHz (0.8 V ± 0.2 V), overload protection
- Input level range: -65dBm ~ -25dBm
- Loop: loop signal
- DVB-S / S2 channel decoder
- Standard DVBS Demod: DVB-S, DVB-S2
- DVBS demodulation: QPSK, 8PSK, 16APSK, 32APSK
- DVBS symbol rate: 2 ~ 90MSPS (1/2 code rate)
- DVBS code rate: 1/2, 2/3, 3/4, 5/6, 7/8 for DVBS QPSK; 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 for DVBS2 QPSK; 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 for DVBS2 8PSK; 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 for DVBS2 16APSK; 3/4, 4/5, 5/6, 8/9, 9/10 for DVBS2 32APSK
- Hardware features
- LNB IN: IEC 169-24, type F, female
- SCART TV: 21 female PIN, CVBS, audio L / R
- S / PDIF: coaxial • Ethernet: RJ45 10 / 100M Ethernet interface
- USB: 2 * USB 2.0
- DV output: 19 pin female HDMI 1.3b
- TS Demux
- Demultiplexer: MPEG2 ISO / IEC 13818-1
- Input bit rate: Max. 100Mbit / s
- Video decoding
- Video decoding: MPEG2 ISO / IEC 13818-2 MP @ ML, H.264 (MPEG4 part 10) main profile level and high 4.1 / MPEG-2 MP @ HL, main profile HEVC @ level 4.1, main profile 10 @ level 4.1
- Aspect ratio: 4: 3, 16: 9
- Video resolution: 1920 × 1080, 1280 × 720, 720 × 480, 720 × 576
- Audio decoding
- Audio decoding: MPEG-1 layerI / II, PCM downmix, IEC958 S / PDIF, Dolby 5.1 channel, Dolby downmix 2 channel, Dolby Prologic 2
- Sound mode: LEFT / RIGHT / STEREO / MONO
- Sample Rate: 32KHz, 44.1KHz, 48KHz
- AV output
- Video bandwidth: SD: 5.0MHz (-3dB), HD: 30MHz (-3dB)
- Video impedance: 75Ω
- Video voltage level: 1.0 Vp-p
- Audio frequency range: 20 ~ 20KHz
- Audio impedance: 600Ω
- Audio voltage level: 2V rms (5.6Vp-p)
- Environment
- Input voltage: DC 12V / 1A
- Consumption: Max. 12W
- Storage temperature: -40 ° ~ 60 °
- Operating temperature: -5 ° ~ 45 °
- Humidity: <95%
- Net Weight: 530g
Data sheet
- Weight
- 388 g
- Power
- DC 12 V / 250 mA, 3 w max
- Resolution
- 1080P at 30 FPS
- Temp. operation
- -40º C ~ +60º C
- Degree of protection
- Weatherproof IP67
- Dimensions
- 161.1 (D) x 70 (W) x 70 (H) mm
180 (D) x 40 (H) x 65 (W) mm - Operating temperature
- 0º C ~ 40º C
- Power supply
- 90 W (Max. 56 V DC)
- Material
- Metallic
- Range
- ULTRA
- Video output
- 1 x BNC switchable between HDTVI / HDCVI / AHD / CVBS
- Audio
- Built-in microphone (Audio via coaxial cable)
- Image sensor
- 2 MP CMOS Night Colour
- Minimum illumination
- 0.0005 Lux @(F1.2, AGC ON)
- Basic functions
- OSD menu (remote)
- Configurable OSD functions
- WDR (130dB), 3D DNR, WDR, BLC, HLC, HLS, Mirror, Anti-Banding, Defective Pixel Correction Smart Light
- Lens
- 2.8 mm
- Maximum resolution
- 2 Mpx (1920x1080)
- Day / Night
- Colour
- PoE features
- According to IEEE 802.3af/at/bt
- Maximum range
- 100 meters
- Interface
- Input / Output RJ45 of 10/100/1000Mbps
- Base diameter
- 55 (Ø) mm / 3 screws
- Lens Adjustment
- 3 Axis
- Video output switching
- Via Switch
